Quick Details
-
Model Number:
-
SAE100 R1 AT
-
Product name:
-
Hydraulic hose SAE100 R1
-
Interial hose:
-
Synthetic rubber, extruded whole without jionts, of uniform thickness
-
Covering:
-
Antiabrasive synthetic rubber, resistanct oils, fuels, atrmospheric.
-
Reinforcement:
-
1 steel wire braided
-
Working pressure:
-
88 bar -225bar/1276psi-3262psi
-
Impulse times:
-
≥ 150 000 times
-
Operating temperature:
-
-40 to 100 ℃
-
Recommended fluid:
-
Mineral and biological oils, water lubricants
-
Flame resistance:
-
U.S. MSHA Approved & CHN MA Approved
Quick Details
-
Processing Service:
-
Moulding, Cutting Assembly
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Yousisheng (YSS)
-
Model Number:
-
SAE100 R1 AT
-
Product name:
-
Hydraulic hose SAE100 R1
-
Interial hose:
-
Synthetic rubber, extruded whole without jionts, of uniform thickness
-
Covering:
-
Antiabrasive synthetic rubber, resistanct oils, fuels, atrmospheric.
-
Reinforcement:
-
1 steel wire braided
-
Working pressure:
-
88 bar -225bar/1276psi-3262psi
-
Impulse times:
-
≥ 150 000 times
-
Operating temperature:
-
-40 to 100 ℃
-
Recommended fluid:
-
Mineral and biological oils, water lubricants
-
Flame resistance:
-
U.S. MSHA Approved & CHN MA Approved
R1 R2 R16 R17 4SP 4SH R13 R15 R5 Steam hose 1W steam
SAE100 R1 AT DIN EN857 1SC ISO 11237 1SC
| Product name | Hydraulic hose SAE100 R1AT/EN853 1SN |
| Brand name | Yousisheng (YSS) |
| Interial hose |
Synthetic rubber, extruded whole without jionts, of uniform thickness |
| Covering | Antiabrasive synthetic rubber, resistanct oils, fuels, atrmospheric. |
| Reinforcement | 1 steel wire braided |
| Working pressure | 88 bar -225bar/1276psi-3262psi |
| Impulse times | ≥ 150 000 times |
| Operating temperature | -40 to 100 ℃ |
| Recommended fluid | Mineral and biological oils, glacol waterbased, water lubricants |
| Flame resistance | U.S. MSHA Approved & CHN MA Approved |
Size:
Product details:
Other products:
|
Wire braid Hydraulic Hose |
SAE100R1AT SAE100R2AT SAE100R1A SAE100R2A DINEN857 1SC DINEN857 2SC SAE100 R16/2SC SAE100 R17 3SW-3Laylines steel wires DIN EN853 1TE/SAER6 EN8542TE SAE100R3 SAE100 R%BX SAE100 R5 CX |
|
Steel Spiral Wire Hydraulic Hose |
EN856 4Sh EN856 4SP SAE100 R12 SAE100 R13 SAE100 R15 |
|
Pressure Washer Hose |
DIN EN JET WASHER 1W (Red +155 °C ) DIN EN JET WASHER 2W (Red +155 °C ) JET WASHER HOSE 1W 155 °C (max) JET WASHER HOSE 2 W 155 °C (max) JET WASHER HOSE 2SC 155 °C (max) JET WASHER HOSE 1W 135 °C (max) JET WASHER HOSE 2 W 135 °C (max) JET WASHER HOSE 2SC 155 °C (max) |
|
Fuel Dispensing Hose |
FUEL DISPENSING HOSE-Type 1/EN1360 1W STEEL WIRE (HARD WALL) FUEL DISPENSING HOSE-Type 2/EN1360 2T STEEL WIRE (HARD WALL) FUEL HOSE-SAE J30 R2ype 3: TEXTILE BRAID FUEL HOSE-SAE J30 R2ype 3: TEXTILE BRAID |
| Industrial Hose |
Oil hose 1TB/1 Textile braid Oil hose 2TB/2Textile braid Oil hose 2TB/2Textile braids: Green color Air /Water Hose, Exceeds SAE J1402 Type A Steam Hose 1SW/B Max 135 °C (Interimittent 155°C) Steam hose 2SW/B Max 135 °C (Interimittent 155 °C) SAE R3 DIN EN853 1TE/SAE100 R6,Wrapped DIN EN853 2TE ,Wrapped SAE20 R3, Water and ethylene glycol based engine coolant system SAE J30 R6-Type 4: Textile braid: Fuel hose SAE100 R5 BX 1 35 °C(Max) Blue color SAE100 R5 BX 15 5 °C(Max) Blue color |
|
Hydraulic hose Assembly |
Capacity:
1,000,000 meters per month (12 million meters per year)
Yousisheng technology team has developed and customized more than 120 kinds of products for customers. And we will continue to maintain an active R&D atmosphere, provide new hydraulic hose solutions for cutomers, and provide a wide range of reliable product lines.
