Quick Details
-
Blade Length (mm):
-
4000 mm
-
Backgauge Travel (mm):
-
20 - 600 mm
-
Throat Depth (mm):
-
100 mm
-
Brand Name:
-
METL
-
Power (kW):
-
11 kW
-
Weight (KG):
-
8200 KG
-
Place of Origin:
-
Shandong, China
-
Marketing Type:
-
Hot Product 2022
-
Model:
-
MES-12Y
-
Work Thickness:
-
8mm
-
Work Width:
-
4000mm
-
Work Angle:
-
1.5°
-
Strokes:
-
8mm
-
Backgauge Range:
-
20-600mm
-
Saw blade size:
-
1100*80*20mm
-
Motor Power:
-
11kw
-
Press Cylinders:
-
15
-
Size:
-
4700*1900*1760mm
Quick Details
-
Max. Cutting Width (mm):
-
4000
-
Max. Cutting Thickness (mm):
-
8 mm
-
Shearing Angle:
-
1.5°
-
Blade Length (mm):
-
4000 mm
-
Backgauge Travel (mm):
-
20 - 600 mm
-
Throat Depth (mm):
-
100 mm
-
Brand Name:
-
METL
-
Power (kW):
-
11 kW
-
Weight (KG):
-
8200 KG
-
Place of Origin:
-
Shandong, China
-
Marketing Type:
-
Hot Product 2022
-
Model:
-
MES-12Y
-
Work Thickness:
-
8mm
-
Work Width:
-
4000mm
-
Work Angle:
-
1.5°
-
Strokes:
-
8mm
-
Backgauge Range:
-
20-600mm
-
Saw blade size:
-
1100*80*20mm
-
Motor Power:
-
11kw
-
Press Cylinders:
-
15
-
Size:
-
4700*1900*1760mm
|
Model
|
Work Thickness
|
Work Width
|
Work Angle
|
Strokes
|
Motor Power
|
|
MES-12Y
|
mm
|
mm
|
°
|
mm
|
kw
|
|
4×2500
|
4
|
2500
|
1°30′
|
22
|
4
|
|
4×3200
|
4
|
3200
|
1°30′
|
20
|
5.5
|
|
4×4000
|
4
|
4000
|
1°30′
|
18
|
5.5
|
|
6×2500
|
6
|
2500
|
1°30′
|
18
|
7.5
|
|
6×3200
|
6
|
3200
|
1°30′
|
16
|
7.5
|
|
6×4000
|
6
|
4000
|
1°30′
|
14
|
7.5
|
|
6×5000
|
6
|
5000
|
1°30′
|
10
|
7.5
|
|
6×6000
|
6
|
6000
|
1°30′
|
7
|
7.5
|
|
8×2500
|
8
|
2500
|
1°30′
|
12
|
11
|
|
8×3200
|
8
|
3200
|
1°30′
|
10
|
11
|
|
8×4000
|
8
|
4000
|
1°30′
|
8
|
11
|
|
8×5000
|
8
|
5000
|
1°30′
|
7
|
15
|
|
8×6000
|
8
|
6000
|
1°30′
|
6
|
15
|
|
10×2500
|
10
|
2500
|
1°30′
|
12
|
15
|
|
10×3200
|
10
|
3200
|
1°30′
|
10
|
15
|
|
10×4000
|
10
|
4000
|
1°30′
|
8
|
15
|
|
12×2500
|
12
|
2500
|
1°30′
|
10
|
18.5
|
|
12×3200
|
12
|
3200
|
1°30′
|
9
|
18.5
|
|
12×4000
|
12
|
4000
|
1°30′
|
8
|
18.5
|
|
12×5000
|
12
|
5000
|
1°30′
|
6
|
18.5
|
|
16×2500
|
16
|
2500
|
2°
|
8
|
22
|
|
16×3200
|
16
|
3200
|
2°
|
8
|
22
|
|
16×4000
|
16
|
4000
|
2°30′
|
6
|
22
|
|
16×6000
|
16
|
6000
|
1°51′
|
6
|
37
|
|
20×3200
|
20
|
3200
|
2°30′
|
5
|
30
|
|
20×4000
|
20
|
4000
|
2°30′
|
5
|
30
|
|
25×2500
|
25
|
2500
|
3°12′
|
5
|
45
|
|
25×3200
|
25
|
3200
|
3°
|
5
|
45
|
MET REIGN
is the professional manufacturerengaged in the research, development, production, sale and service of metal machinery. We always try to provide complete and thoughtful proposal to customers by our speciality and experience.
