Quick Details
-
Row Distance(mm):
-
0 - 120 mm
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Miracle
-
Dimension(L*W*H):
-
2100*880*730mm
-
Weight:
-
180 KG
-
Name:
-
Tractor mounted Garlic Harvester
-
Process Material:
-
Garlic, Potato, Sweet Potato
-
Machine Material:
-
Iron
-
Function:
-
Harvester mini type and combined type
-
Color:
-
Green/White/Yellow as your choice
-
Production capacity:
-
3-5acre/hour
-
Power:
-
20-35hp
-
Functions:
-
harvesting, excavating, and choosing
-
Breakage rate:
-
≤2%
Quick Details
-
Number of Rows:
-
2
-
Working Width(mm):
-
1320 mm
-
Tractor Power(HP):
-
0.5 - 1.5 HP
-
Row Distance(mm):
-
0 - 120 mm
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Miracle
-
Dimension(L*W*H):
-
2100*880*730mm
-
Weight:
-
180 KG
-
Name:
-
Tractor mounted Garlic Harvester
-
Process Material:
-
Garlic, Potato, Sweet Potato
-
Machine Material:
-
Iron
-
Function:
-
Harvester mini type and combined type
-
Color:
-
Green/White/Yellow as your choice
-
Production capacity:
-
3-5acre/hour
-
Power:
-
20-35hp
-
Functions:
-
harvesting, excavating, and choosing
-
Breakage rate:
-
≤2%
Tractor mounted Garlic Harvester/Double Row Potatoes Harvester with automatic discharging
Tractor mounted Garlic Harvester is composed of cutting seeding organization, filed wheels, girders, excavating a shovel, transporting chains, choosing sieve.
- The Harvester can finish the working such as harvesting, excavating, and choosing .
- It mainly includes the middle drive transmission and the left-side drive transmission, which are totally suitable different types of tractors.
How to operate Tractor mounted Garlic Harvester
- Hang the harvester on the tractor which is 22-35hp.
- Connecting the output pulley of the tractor and the input pulley of the harvester by veer belt at the same time.
- Rolling the pulley by hands and see if it is blocked. If yes, please do be eliminating the blocks immediately.
- Make sure the pinch roller has pressed on the belt well in case it loose during the process of elevating.
- When operate the unequipped machine, please be stable and smooth.
- Before starting to work, adjusting the height of the round to assure the digging height to be 10-15cm.
|
Model |
MRC - SH 1 |
MRC - SH2 |
MRC - SH3 |
MRC - SH4 |
MRC - SH5 |
|
Row number |
S ingle row |
Single row (vibration ) |
D ouble row |
D ouble row |
D ouble row(Set pile ) |
|
Row spacing cm |
55-80 |
55-80 |
55-80 |
55-80 |
55-80 |
|
Productivity acre/h r |
3-5 |
5-8 |
|||
|
Total weight Kg |
180 |
160 |
500 |
700 |
800 |
|
Matching p o wer HP |
20-35 |
22-25 |
50 |
50 |
50 |
|
D imension( cm) |
240*90*90 |
120*100*75 |
280*220*100 |
280*220*100 |
280*220*100 |
|
Packing dimension cm |
210*88*73 |
150*90*70 |
220*190*80 |
220*190*80 |
220*190*80 |
|
Breakage rat e (%) |
≤2% |
||||
Photos of Tractor mounted Garlic Harvester
We Provide the Integrated Customer Service System
Pre sale s: Consulting, Designing, Equipment selection, Technology Discussion.
During sales : Programs and drawings confirmed, Installation guide, Equipment debugging.
After sales: Testing acceptance, Customer training, Technical exchanges, Regular visits.
Guarantee and Maintance of Tractor mounted Garlic Harvester
- Tractor mounted Garlic Harvester and all the products purchased in ours are guaranteed to keep in good repair for one year.
- If quality problems happen in guarantee period, our company will maintain for free . Additionally, our company provides technical support and fittings for life.
- After-sales service isn't restricted by time and we will solve your problems in time.
