Quick Details
-
Dimension(L*W*H):
-
7000mm *2200mm *2100mm (Transportation)
-
Weight:
-
16500 KG
-
Mobility:
-
2km/h
-
Borehole Diameter:
-
64-89mm
-
Rock Drill Rod:
-
T38*3050
-
Travel Speed:
-
2km/h
-
Rotation Rate:
-
0-200rpm
-
Rotation Torque:
-
280Nm
-
Feed Extension:
-
1200mm
-
Feeding Stroke:
-
4100mm
-
Feeding Rate:
-
0-0.6m/s
-
Lifting Rate:
-
0-1.2m/s
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
China Brand
-
Voltage:
-
--
-
Dimension(L*W*H):
-
7000mm *2200mm *2100mm (Transportation)
-
Weight:
-
16500 KG
-
Mobility:
-
2km/h
-
Borehole Diameter:
-
64-89mm
-
Rock Drill Rod:
-
T38*3050
-
Travel Speed:
-
2km/h
-
Rotation Rate:
-
0-200rpm
-
Rotation Torque:
-
280Nm
-
Feed Extension:
-
1200mm
-
Feeding Stroke:
-
4100mm
-
Feeding Rate:
-
0-0.6m/s
-
Lifting Rate:
-
0-1.2m/s
|
Borehole Diameter
|
φ64-φ89mm
|
|
Drilling Depth
|
15m
|
|
Rock Drill Rod
|
T38×3050
|
|
Travel Speed
|
2km/h
|
|
Rotation Rate
|
0-200rpm
|
|
Rotation Torque
|
280Nm
|
|
Feed Extension
|
1200mm
|
|
Feeding Stroke
|
4100mm
|
|
Feeding Rate
|
0-0.6m/s
|
|
Lifting Rate
|
0-1.2m/s
|
|
Grade Ability
|
20°
|
|
Lifting Force
|
18kN
|
|
Feeding Force
|
12kN
|
|
Rated Air Pressure of Rock Drill
|
0.5-0.6MPa
|
|
Air Consumption of Rock Drill
|
215L/S
|
|
Impact of Rock Drill
|
≥220J
|
|
Water Pressure of Rock Drill
|
0.4MPa
|
|
Dimension (L × W × H)
|
7000mm × 2200mm × 2100mm (Transportation)
|
|
Weight
|
6T
|
|
Dry Type Dust Collector
|
Optional
|
Product Features
JK410 is a new generation pneumatic tophammer drill rig, the latest updated products of the "Sharp Sword" series, specially
designed for the hydropower project and quarry mining project. JK410 can drill boreholes of various angles, ranging from
horizontal angle to vertical angle. It boasts its better performance, compact design, small footprint and humanized operation.
JK410 can be additionally equipped with dust collection system, and as long as water is accessed, wet type dust collection system
is optional.
JK410 is a new generation pneumatic tophammer drill rig, the latest updated products of the "Sharp Sword" series, specially
designed for the hydropower project and quarry mining project. JK410 can drill boreholes of various angles, ranging from
horizontal angle to vertical angle. It boasts its better performance, compact design, small footprint and humanized operation.
JK410 can be additionally equipped with dust collection system, and as long as water is accessed, wet type dust collection system
is optional.
