Quick Details
-
Model Number:
-
TS-LA-001
-
Input voltage and current:
-
100-240VAC 50/60HZ
-
output voltage and current:
-
6v0.5a 6v1a
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
6v battery charger
-
Input:
-
100-240VAC 50/60HZ
-
Input plug:
-
EU US UK AUS KOREA
-
Output:
-
6v0.5a 6v1a
-
Output Connector:
-
Customized
-
Charge mode:
-
CC---CV---Float
-
Certificate:
-
CE UL PSE KC GS ROHS FCC
-
Led Display:
-
Red--chargiing; Green--full
-
Warranty:
-
2 Years
Quick Details
-
Type:
-
Electric
-
Function:
-
other
-
Brand Name:
-
TengShun
-
Model Number:
-
TS-LA-001
-
Input voltage and current:
-
100-240VAC 50/60HZ
-
output voltage and current:
-
6v0.5a 6v1a
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
6v battery charger
-
Input:
-
100-240VAC 50/60HZ
-
Input plug:
-
EU US UK AUS KOREA
-
Output:
-
6v0.5a 6v1a
-
Output Connector:
-
Customized
-
Charge mode:
-
CC---CV---Float
-
Certificate:
-
CE UL PSE KC GS ROHS FCC
-
Led Display:
-
Red--chargiing; Green--full
-
Warranty:
-
2 Years
TengShun sla/vrla/lead acid battery pack charger 6v 7ah lead acid battery charger
A.product descriptions
Application
♦ Electric vehicle, Ebike, Electric Scooter, Mortor, Golf car,
car jumper
♦ Solar Systems, Home Application,UPS
♦ LED Torch, headlight, Portable power bank,etc.
Electrical Specification
♦ Universal Input: 100 – 240V AC, 50/60Hz
♦ Input Plug: EU US UK AU South Korea South Africa Power cords
♦ Output Voltage Range of main products: 4.2~60V DC (Optional)
♦ Output Current Range of main products: 0.5-100A (Optional)
♦ Output: 6v0.5a 6v1a
♦ Charge mode: CC--CV--Float Mode(Lead acid battery charger)
6V Float Voltage: 6.8V(6.7-6.9V), Top Voltage: 7.3V(7.2-7.4V)
12V Float Voltage: 13.8V(13.6-14.0V), Top Voltage: 14.6V(14.4-14.8V)
18V Float Voltage: 20.7V(20.4-21.0), Top Voltage: 21.9V(21.6-22.2V)
24V Float Voltage: 27.6V(27.2-28.0), Top Voltage: 29.2V(28.8-29.6V)
36V Float Voltage: 41.4V(41.3-42.0), Top Voltage: 43.8V(43.5-44.4V)
48V Float Voltage: 55.2V(54.8-55.6), Top Voltage: 58.4V(58.0-59.2V)
60V Float Voltage: 69.0V(68.5-69.5), Top Voltage: 73.0V(72.5-74.0V)
♦ Led display: Red--in charging; Green--fully Charge
♦ Cut-off Current: 10-15% of Charge current
♦ Output Connector: 3pin Aviation Plugs, XLR socket, DC Jack, Alligator Clips, SAE connector, Anderson Plugs, RCA
♦ Ripple & Noise:1% of Output Voltage
Mechanical Specification
♦ Size: 73*28*42mm
♦
Type: Wall Mount Type
Q1. What are your main products?
Power Supply: 0-150W with 3V 4.5V 5V 6V 7V 9V 10V 12V 15V 18V 19V 20V 24V 25V 30V 36V 48V 60V Outputs
Battery Chargers within 1500W
Lithium/Lipo battery charger
Lifepo4 battery charger
Lead acid battery charger
Nimh/Nicd battery charger
Q2. What is the warranty of your products?
A: 2 years. we can offer the new ones to replace that defective products under warranty.
Q3: What certifications you have?
A: CE ROHS CB GS FCC UL SAA KC KCC PSE CCC for most of products
Q4. What is the lead time?
A: 2-5 days for samples, 12-15 days for mass order. 14 days for new designing.
Q5. What is the shipping way?
A: samples by air, mass order by air or sea. air shipment always choose Fedex,TNT, UPS, DHL with 4-5 days arrival.
Q6. What is the charging mode for your battery chargers?
CC--CV mode for Lithium ion/Lifepo4 Battery charger
CC--CV--Float mode for lead acid battery
CC--CV--Trickle mode for nimh battery
