Quick Details
-
Power:
-
4kw
-
Min. Lifting Height:
-
1880mm
-
Table Size:
-
2.28*1.15*1.263m
-
Overall Dimensions:
-
2.485m*1.39m*2.50m
-
Weight:
-
3180 kg, 3180kg
-
Model name:
-
Z10T
-
Max. Working Height:
-
11.8m
-
Max. Platform Height:
-
9.8m
-
Platform Extension Length and Load:
-
0.9m/113kg
-
Max. Lift capacity:
-
318kg
-
Platform size:
-
2.28*1.15*1.263m
-
Dimensions:
-
2.485m*1.39m*2.50m
-
Wheelbase:
-
1.8m
-
Max. Platform occupancy:
-
2
Quick Details
-
Warranty:
-
5 years
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
MORN LIFT
-
Power:
-
4kw
-
Min. Lifting Height:
-
1880mm
-
Table Size:
-
2.28*1.15*1.263m
-
Overall Dimensions:
-
2.485m*1.39m*2.50m
-
Weight:
-
3180 kg, 3180kg
-
Model name:
-
Z10T
-
Max. Working Height:
-
11.8m
-
Max. Platform Height:
-
9.8m
-
Platform Extension Length and Load:
-
0.9m/113kg
-
Max. Lift capacity:
-
318kg
-
Platform size:
-
2.28*1.15*1.263m
-
Dimensions:
-
2.485m*1.39m*2.50m
-
Wheelbase:
-
1.8m
-
Max. Platform occupancy:
-
2
Products Introduction
Product Parameters
|
Models
|
Z08T
|
Z10T
|
Z12T
|
|
Max. Working Height
|
9.9m
|
11.8m
|
13.6m
|
|
Max. Platform Height
|
7.9m
|
9.8m
|
11.6m
|
|
Platform Dimensions
|
2.28*1.15*1.263m
|
2.28*1.15*1.263m
|
2.28*1.15*1.263m
|
|
Length-stowed
|
2.485m
|
2.485m
|
2.485m
|
|
Width-stowed
|
1.39m
|
1.39m
|
1.39m
|
|
Height-stowed
|
2.38m
|
2.50m
|
2.624m
|
|
Height -stowed( folding guardrails)
|
1.88m
|
1.998m
|
2.116m
|
|
Length/load of Extended Platform
|
0.9m/113.3kg
|
0.9m/113.3kg
|
0.9m/113.3kg
|
|
Wheelbase
|
1.8m
|
1.8m
|
1.8m
|
|
Weight
|
2980kg
|
3180kg
|
3380kg
|
|
Max. Lift capacity
|
450kg
|
318kg
|
318kg
|
|
High driving speed
|
3.2km/h
|
3.2km/h
|
3.2km/h
|
|
Low driving speed
|
0.8km/h
|
0.8km/h
|
0.8km/h
|
|
Gradeability -stowed
|
25%
|
25%
|
25%
|
|
Lifting speed - raise
|
6-8m/min
|
6-8m/min
|
6-8m/min
|
|
Lifting speed - lower
|
10-12m/min
|
10-12m/min
|
10-12m/min
|
|
Battery
|
8×6V/225Ah
|
8×6V/225Ah
|
8×6V/225Ah
|
|
Charger
|
30A
|
30A
|
30A
|
