- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
JCW-CST01
-
Function:
-
Side 1: stripping, crimping; Side 2: stripping, twisting
-
Wire Range:
-
0.03-2mm2 (4mm2 on request)
-
Cutting Length:
-
45-9999mm
-
Stripping Length:
-
1.5-10mm
-
Peripheral:
-
CFM, Belt Conveyor
-
Weight:
-
308kg
-
Stripping Increment:
-
0.1mm
-
Productivity:
-
4200 pcs/hr (L≤300mm)
-
Dimension:
-
L650 x W700 x H1500mm
-
Cutting Tolerance:
-
1mm+0.002 x L
Quick Details
-
Usage:
-
Automatic Wire Crimping
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JCWelec
-
Model Number:
-
JCW-CST01
-
Function:
-
Side 1: stripping, crimping; Side 2: stripping, twisting
-
Wire Range:
-
0.03-2mm2 (4mm2 on request)
-
Cutting Length:
-
45-9999mm
-
Stripping Length:
-
1.5-10mm
-
Peripheral:
-
CFM, Belt Conveyor
-
Weight:
-
308kg
-
Stripping Increment:
-
0.1mm
-
Productivity:
-
4200 pcs/hr (L≤300mm)
-
Dimension:
-
L650 x W700 x H1500mm
-
Cutting Tolerance:
-
1mm+0.002 x L
|
Function
|
Cut depth, Strip length, Full stripping, Partial stripping. Side 1: stripping, crimping. Side 2: stripping, twisting ( optional )
|
|
Wire cross-section
|
0.1 - 2 mm² (AWG 28 - 14) [ 4mm² on request ]
|
|
Strip length
|
1.5-10 mm
|
|
Strip length increment
|
0.1 mm
|
|
Cut length ( L )
|
45 - 999999 mm
|
|
Cut length accuracy
|
± 1mm + 0.002 x L
|
|
Production rate
|
4200 pcs/h by 300mm wire length
|
|
Crimping force
|
20 KN ( 2.0 tons ) [40 KN on request]
|
|
Optional peripheral
|
Wire pre-feeder, CFM, wire stacker
|
|
Detection
|
Wire lack, Wire knot, Terminal crimping, Air pressure
|
|
Power supply
|
AC 220 V ± 10%, 50 / 60 Hz [110V on request]
|
|
Air supply
|
0.4 ~ 0.7 MPa [ clean and dry air ]
|
|
Dimensions
|
L 650 x W 750 x H 1500 mm. 310KG
|
