Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Prevail
-
Model Number:
-
WDT-1200D
-
produce name:
-
professional encryption type iptv satellite receiver with CI slots
-
Operating Frequency Range:
-
950~2150Mhz
-
Receiving Signal Level Range:
-
-65~ -25dBm
-
Image Resolution:
-
720*576(PAL);720*480(NTSC)
-
TS IP output/input:
-
RJ45 100Base-T 70Mb/s
-
SDI output:
-
1X2 BNC-Female
-
ASI output:
-
1X2 BNC-Female
-
The number of CIM module:
-
Two
-
Video decoding:
-
MPEG-2
Quick Details
-
FTA(Free To Air):
-
Yes
-
Type:
-
Digital
-
High Definition:
-
NO
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Prevail
-
Model Number:
-
WDT-1200D
-
produce name:
-
professional encryption type iptv satellite receiver with CI slots
-
Operating Frequency Range:
-
950~2150Mhz
-
Receiving Signal Level Range:
-
-65~ -25dBm
-
Image Resolution:
-
720*576(PAL);720*480(NTSC)
-
TS IP output/input:
-
RJ45 100Base-T 70Mb/s
-
SDI output:
-
1X2 BNC-Female
-
ASI output:
-
1X2 BNC-Female
-
The number of CIM module:
-
Two
-
Video decoding:
-
MPEG-2
encryption iptv satellite receiver with CI slots
Satellite TV Receiver (WDT-1200D)
l SCPC/MCPC and C/Ku band compatible
l C ompatible with DVB-C
l C ompatible with MPEG-2 MP@ML
l Supports PAL, NTSC or SECAM
l Supports TS over IP 100M input/output (IP optional) , support MPTS and SPTS
l With two common interface slot
l Multi-channel encrypted programs by the specific CAM
l S upports various CAS (Conax, Cryptoworks, Irdeto, NDS, Mediaguard, SECA, Viaccess, Compunicate, etc.)
l SDI video output with digital audio embedded
l Two sets of independent ASI outputs
l Teletext VBI, EBU subtitle and DVB subtitle
l DiSEqC1.2, choose channel fast, multi-satellite multi-LNB function
l Memory protection for power-fail
l Multi-languages and interfaces for choosing
l L ocal keyboard control and LCD display , or access via Ethernet link
Pls see the manual before use the equipment;18 months free warranty for optical transmitter,EDFA and digital equipments(natural disaster and anthropic loss are not included);one year for RF Amplifier,splitter&Tap,optical splitter);Prevail will provide 0.5% of order quantity parts for free (example for the power supply and display etc).If there is a problem ,pls send email to us,we will try to solve it by our engineer.
