Quick Details
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
≥30T
-
Drive Wheel:
-
4X2
-
After-sales Service Provided:
-
Field maintenance and repair service, Online support, Onsite Installation, Video technical support
-
Place of Origin:
-
China
-
Cargo Tank Dimension:
-
10120*6350*4935mm
-
Payload Class:
-
110t/120ton
-
Engine Power:
-
899 kW
-
Max Speed:
-
50km/h
-
Fuel Tank:
-
1200L/7gal
-
Length:
-
10120mm
-
Width:
-
6350mm
-
Loading height:
-
4935mm
-
Engine Model:
-
MTU 16V2000C22
-
Drive Mode:
-
Independent Four Wheel
Quick Details
-
Condition:
-
New
-
Horsepower:
-
351 - 450hp
-
Emission Standard:
-
Euro 2
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
≥30T
-
Drive Wheel:
-
4X2
-
After-sales Service Provided:
-
Field maintenance and repair service, Online support, Onsite Installation, Video technical support
-
Place of Origin:
-
China
-
Cargo Tank Dimension:
-
10120*6350*4935mm
-
Payload Class:
-
110t/120ton
-
Engine Power:
-
899 kW
-
Max Speed:
-
50km/h
-
Fuel Tank:
-
1200L/7gal
-
Length:
-
10120mm
-
Width:
-
6350mm
-
Loading height:
-
4935mm
-
Engine Model:
-
MTU 16V2000C22
-
Drive Mode:
-
Independent Four Wheel
Product Display
VTH3310 Electric Mining Dump Truck
ENERGY SAVING
Can be equipped with LNG hybrid engine, achieve environmental protection and energy saving.
LONG SERVICE LIFE
Ac electric drive system, low maintenance cost and long lifetime.
Independent dual rear axles+swing axle +four rear independent driving tires design, the truck is more powerful, each tire's load is evenly and lifetime is longer.
ECONOMIC STABILITY
Higher payload capacity, excellent fuel efficiency.
Wide distance between supporting point of the dump body, the truck is reliable.
INTELLIGENT EXTENSION
The truck setting meets the requirements of intelligent interface, which can realize unmanned driving rapid transformation of vehicles, and effectively promote the innovative development of smart mines.
Dimension
Machine Main Technical Parameters
