Single line rated pull
|
12000lb (5443kg)
|
Motor
|
5.35hp/3.9kw,Series Wound
|
|
Control
|
Remote Switch, Extra long 4.5m lead , In and Out PLUS Twin Handset Wireless Remote
|
Gear train
|
3 Stage Planetary
|
|
Gear reduction ratio
|
265:01:00
|
Clutch
|
Sliding Ring Gear
|
|
Braking Action
|
Automatic In The Drum
|
Drum size
|
Diameter 64mm (2.5")Length 233.5mm(8.82”)
|
|
Cable
|
24m (78ft) of 9.4mm (3/8”)diameter
|
Fairlead
|
4-Way Roller Fairlead
|
|
Battery
|
Recommended 650CCA minimum for winching
|
Battery Leads
|
2 gauge, 1.83m (72”) 25mmsq - 6.5mm Diameter
|
|
Finish
|
Black
|
Weight
|
GW 38KG
|
|
Overall Dimensions(LxWxH)
|
527x160x217mm (19.8"x6.3"x8.5")
|
Mounting Bolt Pattern
|
10.00”±0.015"x4.50”±0.010"(255x114mm)
|
|
Motor Current
|
65-400A
|
No Load Line Speed
|
6.5m/min (21.3 ft/min)
|
