Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Wavelink
-
Model Number:
-
WL-001011
-
Center Frequency:
-
0-6Ghz
-
V.S.W.R:
-
<1.5
-
Impedance:
-
50/75 Ω
-
Maximum input power:
-
50W
-
Working Voltage:
-
500 V RMS
-
Body Couping nut:
-
Brass, Zin Alloy (Diecast)
-
Connector type:
-
BNC Male to SMA Female
-
Body Plating:
-
Nickel (Ni)
-
Insulation Resistance:
-
>5000M Ω
Quick Details
-
Type:
-
BNC
-
Application:
-
RF
-
Gender:
-
Male
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Wavelink
-
Model Number:
-
WL-001011
-
Center Frequency:
-
0-6Ghz
-
V.S.W.R:
-
<1.5
-
Impedance:
-
50/75 Ω
-
Maximum input power:
-
50W
-
Working Voltage:
-
500 V RMS
-
Body Couping nut:
-
Brass, Zin Alloy (Diecast)
-
Connector type:
-
BNC Male to SMA Female
-
Body Plating:
-
Nickel (Ni)
-
Insulation Resistance:
-
>5000M Ω
Products Description
Specification
|
Item
|
Specifications
|
|
|
1) Product Information
|
|
|
|
Place of Origin
|
Jiangsu , China
|
|
|
Brand Name
|
Wavelink
|
|
|
Model Number
|
WL-001011
|
|
|
2) Technical Information
|
|
|
|
Center Frequency
|
0-6Ghz
|
|
|
Gender
|
Male/Female
|
|
|
V.S.W.R
|
<1.5
|
|
|
Impedance
|
50/75 Ω
|
|
|
Maximum input power
|
50W
|
|
|
Dielectric withstanding Voltage
|
1500 V RMS
|
|
|
Working Voltage
|
500 V RMS
|
|
|
Center Contact Resistance
|
<1.5M Ω
|
|
|
Outer Contact Resistance
|
<2.0M Ω
|
|
|
Insulation Resistance
|
>5000M Ω
|
|
|
3) Mechanical Information
|
|
|
|
Body Couping nut
|
Brass, Zin Alloy (Diecast)
|
|
|
Insulator
|
Teflon, Delrin
|
|
|
Center Contact
|
Brass for male
|
|
|
|
Beryllium/ Phosphor Bronze Copper for Female
|
|
|
Body Plating
|
Nickel (Ni)
|
|
|
Center Contact Plating
|
Gold (Au)
|
|
|
4) Environmental Information
|
|
|
|
Operating Temperature
|
-40°C ~ +85°C
|
|
|
Storing temperature
|
-30°C ~ +85°C
|
|
