Quick Details
-
Model Number:
-
1M Series
-
Max. Current:
-
Gold: 0.4VA (maximum) at 20V (maximum) (AC or DC)
-
Mechanical Life:
-
40,000 make-and-break cycles
-
Applications:
-
Telecommunication /Medical equipment /Instrumentation
-
Function:
-
ON-ON,ON-OFF-ON,MOM-OFF-MOM
-
Certifications:
-
UL,ROHS,Lead Free
-
Case:
-
Diallyl phthalate (DAP) (UL94v-0)
-
Actuator:
-
Brass,chrome plated
-
Bushing:
-
Brass,nickel plated
-
Housing:
-
Stainless steel
-
Switch support:
-
Brass,tin plated
-
Housing color:
-
Red
-
Cap color:
-
White,Black,Red,Yellow,Green,Blue,Gray
Quick Details
-
Max. Voltage:
-
Silver:5A at 120VAC or 28VDC/2A at 250VAC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Dailywell
-
Model Number:
-
1M Series
-
Max. Current:
-
Gold: 0.4VA (maximum) at 20V (maximum) (AC or DC)
-
Mechanical Life:
-
40,000 make-and-break cycles
-
Applications:
-
Telecommunication /Medical equipment /Instrumentation
-
Function:
-
ON-ON,ON-OFF-ON,MOM-OFF-MOM
-
Certifications:
-
UL,ROHS,Lead Free
-
Case:
-
Diallyl phthalate (DAP) (UL94v-0)
-
Actuator:
-
Brass,chrome plated
-
Bushing:
-
Brass,nickel plated
-
Housing:
-
Stainless steel
-
Switch support:
-
Brass,tin plated
-
Housing color:
-
Red
-
Cap color:
-
White,Black,Red,Yellow,Green,Blue,Gray
With ourcore technology on the integration of resources, customized requestcan be fulfilled in such a small amount of diversification with fast delivery to meet all the customer’s needs.
We have the professional management team andwe develop the new technology and continuously growing steady to meet all kinds of challenges in front of us.
DailywellElectronics Co., Ltd., has the R&D team that can solve the customer’s non-standard specifications on demand. In accordance with the company system planning, we are updatingthe directions of future productsfor the next 3 to 5 years annually to grow with our customers. Up-to-date with current market changes, starting from technical research and development, establish standard specifications, and expand the type of product lines. Then reinforce the educational training of professional knowledge in all department units after setting the future development strategyso that the whole company goes toward on thesame common goal. Customers always find us trustworthy by cooperating with us. Additional high value is what makes us outstanding in the market. We believe that by collaborating with us, our customers not only just get a switch they need but also get a partner that goes alongin this electronic road.
From the purchase of raw materials to the finished product, all production process (product development/plating/mold and equipment processing/ metalpressing/ plasticinjection/semi-automatic and fully automated equipment assembly, etc.) are completed in the factory.
Our metal pressing and plastic injection own the advantages of 100% self-made mold, from a single form to the various forms of application. And we continuously keep innovation and enhance the technology in order to collaborate with our customers to design the most sophisticated products.
Dailywell Electronics Co., Ltd., whether in production base or in quality assurance department in the head office, have professional equipment and technical personnel. In addition to the annual new product development, product improvement and testing are performed as annual plan to ensure that listed products maintain in best quality. Therefore, our long-term customers/partners, get the best quality of the switches.
We care for environmental protection so we put efforts in creating a pollution-free environment, produce RoHS goods, and regularly implement the environmental verification on our products.
Q: If i want to release order, what's the process?
A: Thanks. You can send inquiry to us by alibaba, or send us by email, we will reply within 24hrs.
Q: What is the payment terms do you accept?
A: We accept T/T in advance, L/C and Western Union.
Q: Do you provide samples ? is it free or extra?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
