Quick Details
-
Size:
-
12700X2500X4000
-
Place of Origin:
-
Shandong, China
-
Product name:
-
3-axle Semi-trailer
-
Suspension:
-
Mechanical Suspension
-
Axle:
-
13 Ton Fuwa Brand
-
King pin:
-
2"(50mm)or3.5"(90mm) JOST
-
Tire:
-
12R22.5
-
Landing Gear:
-
Standard 28Ton
-
Brake System:
-
Dual Line Braking System
-
Keywords:
-
Dump Tipper Trailer
-
Color:
-
Customers Optional
-
Loading capacity:
-
25T~80T
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
50ton
-
Brand Name:
-
Aotong
-
Size:
-
12700X2500X4000
-
Place of Origin:
-
Shandong, China
-
Product name:
-
3-axle Semi-trailer
-
Suspension:
-
Mechanical Suspension
-
Axle:
-
13 Ton Fuwa Brand
-
King pin:
-
2"(50mm)or3.5"(90mm) JOST
-
Tire:
-
12R22.5
-
Landing Gear:
-
Standard 28Ton
-
Brake System:
-
Dual Line Braking System
-
Keywords:
-
Dump Tipper Trailer
-
Color:
-
Customers Optional
-
Loading capacity:
-
25T~80T
|
Specifications of Tanker Body |
|
|
Dimension |
12000mm*2490mm*3990mm( Exact size depends on the final design) |
|
Tare weight kg |
About 11800KGS-13000KGS |
|
Tank capacity |
30cbm-60cbm(Volume optional) |
|
Shape |
Optional(v or w shape) |
|
Compartments |
One or two compartment |
|
Tanker Body Material |
5mm or 6mm/Q235 carbon steel |
|
End Plate |
5mm or 6mm/Q235 carbon steel |
|
Rim |
8.00-20/8.5-20/8.8-20/9.0-22.5 China Brand |
|
Tire |
12R22.5/11R22.5/13R22.5/11.00R20/12.00R20( brand can be Optional) |
|
Engine |
Weichai 4105 Engine |
|
Manhole Cover |
500mm carbon steel or aluminum alloy manhole |
|
Bottom Valve |
3''/ 4” disc valve |
|
Discharging Valve |
Diameter is 3 or 4 inch |
|
Discharging Pipe |
4” rubber hose, 2 pcs, 6m/each |
|
Air compressor |
10 m3,12m3 |
|
Diesel Engine |
Weichai Huafeng, Tianhe 4102/4105 |
|
|
Welding design or Special design, connected by bolts and nuts.
|
|
Axle |
2 or 3 axles, BPW/FUWA brand(Optional) |
|
Landing Gear |
JOST(D200T)or China brand 28T(two speed) |
|
Brake System |
WABCO Valve with big chamber |
|
King Pin |
JOST 2.00 or 3.5 inch bolt-in king pin |
|
Suspension |
Mechanical suspension or Air suspension |
|
Leaf Spring |
90(W)mm×13(Thickness)mm×10(Layer) or 100mm×12mm×12 |
|
Rear ladder |
Dismountable |
|
Lights |
Turning Light, Side Marker Light, Tail Light |
|
Voltage |
24V |
|
Receptacle |
7 ways (7 wire harness) |
|
Painting |
Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
|
ABS |
Optional |
|
Accessories |
One standard tool box |
We transport the semi trailers by bulk or container. Our factory possesses long-term cooperation with ship agency which can provide you lowest shipping fee.
1. Over 15 years professional manufacturer experiences
2. Be designed according to your requirements
3. CCC ISO9001 SGS agreement
4. Small order can be accepted
5. 1 year quality guarantee term
6. We accept 100% inspection, welcome to our factory at any tim
e
