Quick Details
-
Brand Name:
-
BirdUV
-
Rated Power:
-
120W
-
Product name:
-
UV LED Area light Curing System
-
Input Voltage:
-
AC220V
-
Wavelength:
-
365nm 385nm 395nm 405nm
-
LED chips:
-
Seoul
-
Cooling Method:
-
Nature cooling/Fan cooling
-
Irradiance:
-
1.2W/cm2 at 395nm
-
Service time:
-
20000HRS
-
Warranty:
-
1 Year
Quick Details
-
Warranty(Year):
-
1-Year
-
Light Source:
-
LED
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
BirdUV
-
Rated Power:
-
120W
-
Product name:
-
UV LED Area light Curing System
-
Input Voltage:
-
AC220V
-
Wavelength:
-
365nm 385nm 395nm 405nm
-
LED chips:
-
Seoul
-
Cooling Method:
-
Nature cooling/Fan cooling
-
Irradiance:
-
1.2W/cm2 at 395nm
-
Service time:
-
20000HRS
-
Warranty:
-
1 Year
| Name | Specifications | Unit | Parameter |
| UV LED area light source controller | Optional Channel | Channel | CH1,CH2,CH3,CH4 |
| Power setting | mw/cm2 | 0%-100% | |
| Irradiation mode | Manual mode | Touch control, pedal, 0-10V | |
| Automatic mode | Timing Control | ||
| Advanced Mode | Circular Step irradiation | ||
| Control mode | Four | Touch control, pedal, 0-10V, PLC control | |
| Type of cooling | Air-cooled | fan cooling | |
| Votage | 100-240VAC.50/60HZ | ||
| Working Temperature/Humidity | + 5±40°C 20-85% | ||
| Storage emperature/Humidity | -10±60°C 20-85% | ||
| Size | mm | 350*250*150 | |
| Weight | KG | 10KG | |
| Irradiation head specification (BU50-50) | LED type | Ultraviolet LED | |
| Wavelength range | nm | 365.385.395.405…. | |
| Lamp Dimentions | mm | 90*75*120 | |
| Light area | mm | 45*55 | |
| Working distance | mm | 5-30 | |
| Light intensity | mw/cm2 | 0-3000 | |
| Heat-dissipating method | Mandatory | Fan cooling | |
| LED service life | H | 20000 | |
| Electric power | w | 120 | |
| Working Temperature/Humidity | 5±40°C 20-85% | ||
| Storage emperature/Humidity | -10±60°C 20-85% | ||
| Power cord | Cable | m | 2 |
| Connecting Cable | Flexible cable | m | 2 |
