Quick Details
-
Voice Coil Diameter:
-
Copper
-
Former Material:
-
KSV
-
Nominal Impedance:
-
8 Ω
-
Nominal Power handling:
-
120 W
-
Sensitivity (1W/1m):
-
94 dB
-
Frequency Range:
-
55.5-4500 Hz
-
Winding Depth:
-
13 mm
-
Using:
-
line array
-
Site:
-
8 inch
-
Quality:
-
high
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Hiwell
-
Model Number:
-
08HW29
-
Voice Coil Diameter:
-
Copper
-
Former Material:
-
KSV
-
Nominal Impedance:
-
8 Ω
-
Nominal Power handling:
-
120 W
-
Sensitivity (1W/1m):
-
94 dB
-
Frequency Range:
-
55.5-4500 Hz
-
Winding Depth:
-
13 mm
-
Using:
-
line array
-
Site:
-
8 inch
-
Quality:
-
high
line array speaker in professional systerm
1. ideal for pa audio
2.Good performance/ competitive price
| Specifications | ||
| Nominal Diameter | 225*208/9*8 | mm/inch |
| Nominal Impedance | 8 | Ohm |
| Minimum Impedance | 6.2 | Ohm |
| Power handling | ||
| (50-500Hz) | ||
| Nominall | 120 | Watts |
| Continuous Program | 240 | Watts |
| Sensitivity (1W/1m)3 | 94 | dB |
| Frequency Range | 55.5-4500 | Hz |
| Voice Coil Diameter | 49.5/1.9 | mm/inch |
| Winding Material | Copper | outside |
| Former Marerial | KSV | |
| Winding Depth | 13/0.5 | mm/inch |
| Magnetic Gap Depth | 8/0.3 | mm/inch |
| Flux density | 1.2 | T |
| Thiele-Small parameters4 | ||
| Fs | 55.5 | Hz |
| Re | 5.2 | Ohm |
| Qes | 0.29 | |
| Qms | 4.16 | |
| Qts | 0.27 | |
| Vas | 30 | liters |
| η0 | 1.74 | % |
| X max | 2.5 | mm |
| X var | 3.5 | mm |
| Mms | 21.6 | gr |
| BL | 11.7 | N/A |
| Le | 0.7 | mH |
| Mounting and Shipping Information | ||
| Blot Circle Diameter | 207/8 | mm/inch |
| Overall Diameter | 225*208/9*8 | mm/inch |
| Baffie Cutout Diameter | 186/7.3 | mm/inch |
| Depth | 105/4 | mm/inch |
| Flang and Gasket Tickness | 9/0.4 | mm/inch |
| Net Weight | 3.5 | Kg |
| Shipping Weight | 3.6 | Kg |
| Shipping BOX | 470×470×260(8pcs) | mm |
| Magnet Size | 140*60*20 | mm |
