- Product Details
- {{item.text}}
Quick Details
-
Span:
-
Customized
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Dejun
-
Weight (KG):
-
3000 kg
-
Product Name:
-
Single Girder Bridge Crane 5 ton 10ton 40ton Overhead crane
-
Crane feature:
-
Easy Operated Girder Bridge Crane
-
Capacity:
-
0.5-40t
-
Type:
-
suspension overhead crane
-
Power supply:
-
110V/220V/230V/380V/440V
-
Control Method:
-
Ground Control+ Remote Control (customized)
-
MOQ:
-
1 Set
-
Lifting mechanism:
-
Electric Hoist
-
Work Duty:
-
A3-A5
-
After Warranty Service:
-
Video technical support
Quick Details
-
Max. Lifting Height:
-
2.5m, 7.5m, 6m, 4.5m, 30m
-
Rated Lifting Moment:
-
30kn
-
Max. Lifting Load:
-
100t
-
Span:
-
Customized
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Dejun
-
Weight (KG):
-
3000 kg
-
Product Name:
-
Single Girder Bridge Crane 5 ton 10ton 40ton Overhead crane
-
Crane feature:
-
Easy Operated Girder Bridge Crane
-
Capacity:
-
0.5-40t
-
Type:
-
suspension overhead crane
-
Power supply:
-
110V/220V/230V/380V/440V
-
Control Method:
-
Ground Control+ Remote Control (customized)
-
MOQ:
-
1 Set
-
Lifting mechanism:
-
Electric Hoist
-
Work Duty:
-
A3-A5
-
After Warranty Service:
-
Video technical support
Product Paramenters
|
LD Series Single Girder Overhead Crane
|
|
|
|
The parameters are standard ,and customized solutions and designs are provided according to your actual needs.
|
|
|
|
Working Class
|
A3,A4
|
|
|
Capacity(t)
|
0.5-32
|
|
|
Span(m)
|
3-35
|
|
|
Lifting Height(m)
|
3-50
|
|
|
Lifting Speed(m/min)
|
0.33-8,single or dual speed
|
|
|
Trolley Travelling Speed(m/min)
|
2-30,single or dual speed
|
|
|
Crane Travelling Speed(m/min)
|
2-30,single or dual speed
|
|
|
Control Method
|
ground or cab control
|
|
|
Power Supply
|
380v 50hz 3p or customized
|
|
|
Temperature(℃)
|
-20-60
|
|
|
Protection Grade
|
IP44-65
|
|
Basic Pattern
Success case
We have exported to over 120 countries worldwide,If you want to know about local cases, please contact us
Gantry Crane in Uzbekistan
Gantry Crane in Brazil
Gantry Crane in Saudi Arabia
Overhead Crane in Indonesia
Overhead Crane in
Singapore
Overhead Crane in Australia
3D VR Room
Certifications
EAC
ISO
CE
Explosion-proof Certificate
Customer Visit
Exhibition
Packing&Delivery
Recommend Products
HD
European
Single Girder Overhead Crane
Model:HD
Lifting Capacity:
1-25
t
Lifting Height:
3-100
m
Span:3-35m
Working Class:
A5-A7
Customized as your needs
LX Suspension Single Girder Overhead Crane
Model:LX
Lifting Capacity:1~25t
Lifting Height:3-50m
Span:3-20m
Working Class:A3-A4
Customized as your needs
Why Choose Us
1.Communication and efficiency and hopefully can customer is happy with the quality and can cooperate for future
2.Communication was best, response time to my questions was fastest and images where most closely related to what we wanted.
3.
I found your company in the firsts results on Alibaba, and then you offer an interesting price
4.
I saw the cranes that you build in the different counties. It looks impressive I searched for Dejun Singapore
5.
For the ALIBABA.It’s because my agent look at your historic, and indicates for me.
6.
I like your website and I like your email response time and there was not any major misunderstanding so far.Your price was also good, but this was not the most important thing.
7.
I want to see how good is your products cos I think in future this spec is usefully.Singapore only got electric winches.
8.
I have no experience shopping on alibaba. I just saw your shop 1. trade insurance. 2. verified
After Sale
Warranty time：1year
During the after-sales period，if there is any problem with quality based on correct operation, we will send you spare parts for free, because these spare parts are produced by our factory and have a large number of stock. Therefore, we can send to you at any time.We provide 7*24h online service, if there is any problem,please contact us!
As for the installation work:
1.We will send the drawings and instructions to you. After receiving the goods, you can install according to the instructions. If you have any questions, you can contact us at any time to help you complete the installation.
2.We can send engineers to the site to provide installation and commissioning services, and also train workers to operate the crane more safely.
3.You can find engineers in your local area, and our engineers can provide online video guides.
