Quick Details
-
Machine Weight:
-
1100 kg
-
Bucket capacity:
-
0.53m3
-
Product name:
-
Front Wheel Loaders
-
Drive type:
-
4 Wheel Drive
-
Tire Design:
-
Radial
-
Dumping Type:
-
Side Dumping Style
-
Tubeless Tire:
-
12-16.5
-
Max. Speed:
-
11km/H
-
Max. Loading:
-
2200kgs
-
Operating Load:
-
1100kgs
Quick Details
-
Engine Brand:
-
CHANGCHAI
-
Power:
-
55 kw
-
Place of Origin:
-
Henan, China
-
Machine Weight:
-
1100 kg
-
Bucket capacity:
-
0.53m3
-
Product name:
-
Front Wheel Loaders
-
Drive type:
-
4 Wheel Drive
-
Tire Design:
-
Radial
-
Dumping Type:
-
Side Dumping Style
-
Tubeless Tire:
-
12-16.5
-
Max. Speed:
-
11km/H
-
Max. Loading:
-
2200kgs
-
Operating Load:
-
1100kgs
Mini Dumper China Skid loader Cheap Skid EPA Engine Minicargador Skid Steer Track Loader Price
It can carry
3670Kgs/8090lbs/19cu
ft and will climb up a hill with ease.
The new electric Power Barrow 4WD is Ideal Macinery's latest invention which features a four-wheel drive that makes it easy to maneuver and the bucket tips electronically by a touch of a button.
The new electric Power Barrow 4WD is Ideal Macinery's latest invention which features a four-wheel drive that makes it easy to maneuver and the bucket tips electronically by a touch of a button.
Products Description
|
Model
|
HY1100
|
HY1405
|
HY1605
|
||
|
Engine model
|
4C6-88C33(65KW/2200r/min)/4TNV98T-ZNLYS(57.3KW/2400r/min)/S4S-G2DT61(62KW/2500r/min)
|
|
|
||
|
Rated power
|
55KW
|
73.5KW
|
73.5KW
|
||
|
Rotating speed
|
2200rpm
|
2200rpm
|
2200rpm
|
||
|
Max. speed
|
11km/h
|
11/22KM/H
|
10/20KM/H
|
||
|
Tubeless tire
|
12-16.5
|
12-16.5
|
12-16.5
|
||
|
Operating load
|
1100KGS
|
1400KGS
|
1600KGS
|
||
|
Max. loading
|
2200KGS
|
2800KGS
|
3200KGS
|
||
|
Lifting type
|
Radial
|
Radial
|
Vertical
|
||
|
Total cycling time
|
9s
|
11.2s
|
11.2s
|
||
|
Bucket capacity
|
0.53m3
|
0.55m3
|
0.55m3
|
||
|
Pressure of working system
|
235bar
|
235bar
|
235bar
|
||
|
Rated flux
|
69L/min
|
86L/min
|
88L/min
|
||
|
High flow flux
|
138L/min
|
158L/min
|
158L/min
|
||
|
Fuel tank capacity
|
100L
|
82L
|
82L
|
||
|
Self-weight with bucket
|
3670KGS
|
4080KGS
|
4260KGS
|
||
|
HY1100 Optional Configuration
|
|
|
|
Optional engine
|
4C6-88C33(65KW/2200r/min),4TNV98T-ZNLYS(57.3KW/2400r/min),S4S-G2DT61(62KW/2500r/min)
|
|
|
Optional air filter
|
Donaldson 3-stage Air Filter
|
|
|
Optional Air-conditioner
|
Cool Air-conditioner, Cool and Heat Air-conditioner, Heater
|
|
|
Optional Tire
|
Ground TpubelessTire 20-16.5; Small Pattern Pneumatic Tire 12-16.5,
|
|
|
|
Toyo Solid Tire 33X12-20, With Steel Track
|
|
|
Optional Hydraulic Operation System
|
Danfess Hydraulic Pump, Poclain Motor Assembly System, Rexroth System
|
|
|
Optional Fuel System
|
Antifreezing Fuel System for Cold Region
|
|
|
HY1405 Optional Configuration
|
|
|
|
Optional engine
|
1104D-44T
|
|
|
Optional air filter
|
Donaldson 3-stage Air Filter
|
|
|
Optional Air-conditioner
|
Cool Air-conditioner, Cool and Heat Air-conditioner, Heater
|
|
|
Optional Tire
|
Ground TpubelessTire 20-16.5; Small Pattern Pneumatic Tire 12-16.5,
|
|
|
|
Toyo Solid Tire 33X12-20, With Steel Track
|
|
|
Optional Hydraulic Operation System
|
Rexroth Hydraulic System
|
|
|
Optional Fuel System
|
Antifreezing Fuel System for Cold Region
|
|
Ideal machinery showcases
a wide range of tracked mini dumpers, compact machines that are ideal for construction work, renovations, landscaping, work on uneven, muddy, sandy, or sloping ground, and where wheels cannot be used because they sink or lose grip. The models produced by Ideal Machinery are agile and sturdy with a loading capacity of
between 700 kg and 2,900 kg.
One of the keys to the success of this small, but powerful machine is its range of functions, strength, and compact design. Ideal has also invested heavily in technological innovation in the dumper range, the driving force behind all projects, with the goal of producing increasingly high-tech models with the best performance which respects the environment and ensures operator safety.
Product Overview
FEATURE:
1. Easy access points for maintenance work thanks to a smart hood design.
2. Greater power (39kw-45kw) is provided by a three-cylinder, liquid-cooled brand diesel engine.
3. Increased efficiency and productivity, through lower fuel consumption, because you can adjust your speed as required (transmission)
4. Improvements in operator safety by providing levers within easy reach when driving (control panel)
5. Compact and flexible: Small skid steer loaders are small in size and light in weight, making them easy to operate in narrow construction sites or indoor spaces.
6. Strong versatility: The small skid steer loader can be configured with different accessories and interfaces according to needs to achieve multiple functions, such as excavating, leveling, pushing soil, pile driving, tamping, etc., which can be easily replaced.
1. Easy access points for maintenance work thanks to a smart hood design.
2. Greater power (39kw-45kw) is provided by a three-cylinder, liquid-cooled brand diesel engine.
3. Increased efficiency and productivity, through lower fuel consumption, because you can adjust your speed as required (transmission)
4. Improvements in operator safety by providing levers within easy reach when driving (control panel)
5. Compact and flexible: Small skid steer loaders are small in size and light in weight, making them easy to operate in narrow construction sites or indoor spaces.
6. Strong versatility: The small skid steer loader can be configured with different accessories and interfaces according to needs to achieve multiple functions, such as excavating, leveling, pushing soil, pile driving, tamping, etc., which can be easily replaced.
Thickened oil pipe, stable operation, no oil leakage, no oil leakage, reliable quality.
Good fan heat performance, long service life, safety, and energy saving.
Good fan heat performance, long service life, safety, and energy saving.
Product packaging
The company is located in Henan Province. It has in-depth cooperation with foreign customers to develop vehicles and help foreign customers build
CKD or SKD
assembly workshops abroad.
We have many years of experience in vehicle, forklift, and skid steer exporting and have a professional foreign trade team in English, Arabic, and Russian; our products are exported to Tanzania, Ghana, Brazil, Zimbabwe, Central Africa, Thailand, Myanmar, Uzbekistan, and other countries. Our export products cover cargo trucks, sanitation trucks, used trucks, and special trucks, providing foreign customers with high-quality and reliable trucks and services.
Packing: Nude packing after painting wax or according to your requirement.
Shipping: By bulk cargo carrier, RORO, and By sea
We have many years of experience in vehicle, forklift, and skid steer exporting and have a professional foreign trade team in English, Arabic, and Russian; our products are exported to Tanzania, Ghana, Brazil, Zimbabwe, Central Africa, Thailand, Myanmar, Uzbekistan, and other countries. Our export products cover cargo trucks, sanitation trucks, used trucks, and special trucks, providing foreign customers with high-quality and reliable trucks and services.
Packing: Nude packing after painting wax or according to your requirement.
Shipping: By bulk cargo carrier, RORO, and By sea
