Quick Details
-
Application:
-
Apparel
-
Place of Origin:
-
China
-
Brand Name:
-
DEVEUP
-
Power:
-
11KW
-
Dimension(L*W*H):
-
2270*3400*1300mm
-
Weight:
-
1400 KG
-
Features:
-
High precision
Quick Details
-
Production Capacity:
-
1500mm/s
-
Voltage:
-
220V/380V
-
Marketing Type:
-
New Product 2023
-
Application:
-
Apparel
-
Place of Origin:
-
China
-
Brand Name:
-
DEVEUP
-
Power:
-
11KW
-
Dimension(L*W*H):
-
2270*3400*1300mm
-
Weight:
-
1400 KG
-
Features:
-
High precision
Product Description
Applications
Specification
|
Parameters/Model
|
FV1216 FV1625 FV1830 FV1650
|
|
Working Size
|
1200*1600mm 1600*2500mm 1800*3000mm 1600*5000mm (can be customized)
|
|
Cutting thickness
|
≤50mm (Other thickness can be customized according to the material)
|
|
Cutting speed
|
≤1700mm/s(The actual speed depends on the material and cutting graphics)
|
|
Applicable materials
|
Oxford cloth, Nonwoven Fabric, Prepreg, Neoprene, Synthetic Leather, cowhide, fur, PVC, Foam,Acoustic panel, KT board, car stickers, rubber, sponge, carton, film, fiberglass, fabric, carbon fiber, and other materials
|
|
Cutting precision
|
± 0.1mm
|
|
Repeat accuracy
|
≤0.05mm
|
|
Min cutting circular diameter
|
≤1mm Diameter
|
|
Positioning way
|
Laser positioning also optional CCD camera positioning
|
|
Safety device
|
Physical anti-collision mechanism + infrared induction anti-collision to ensure production safety
|
|
Material fixed way
|
Vacuum adsorption
|
|
Production Capacity
|
1500mm/s
|
|
Compatible software
|
AI software, AutoCAD, CorelDRAW, and all of the box type design software can output directly, without conversion, and with automatic optimization
|
|
Support File Format
|
AI, PLT, DXF, PDF
|
|
Operation Panel
|
Multilingual languages LCD touch panel
|
|
Transmission system
|
High precision linear guide, meshing transmission gear and rack structure, high performance servo drive motors + precision reducer
|
|
Dimension(L*W*H)
|
3500*2220*1350mm
|
|
Weight
|
1500KG
|
