Quick Details
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
12500
-
Drive Wheel:
-
6x4
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Overseas Call Centers, Return and Replacement, Field installation, commissioning and training, Online support, Free spare parts, Field maintenance and repair service, Shop warranty, None
-
Brand Name:
-
HOWO
-
Place of Origin:
-
Shandong, China
-
Engine Brand:
-
Imported Brand
-
Gear Box Brand:
-
Imported Brand
-
Dimensions (L x W x H) (mm):
-
8085*2500*3450mm
-
Cargo Tank Dimension:
-
8085*2500*3450mm
-
Product name:
-
sinotruk howo a7 dump truck 380 hp 25 ton capacity for sale
-
PTO:
-
QH50
-
Front axle:
-
7.5T, ,7500kg
-
Rear axl:
-
16T, STR 2x16000kg
-
Driving type:
-
6x4
-
Farm:
-
850x300(8+7)
-
Color:
-
Optional
-
Cargo box size:
-
5600*2300*1500mm
-
Lifting style:
-
front lifting cylinde
Quick Details
-
Condition:
-
New
-
Horsepower:
-
251 - 350hp
-
Emission Standard:
-
Euro 2
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
12500
-
Drive Wheel:
-
6x4
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Overseas Call Centers, Return and Replacement, Field installation, commissioning and training, Online support, Free spare parts, Field maintenance and repair service, Shop warranty, None
-
Brand Name:
-
HOWO
-
Place of Origin:
-
Shandong, China
-
Engine Brand:
-
Imported Brand
-
Gear Box Brand:
-
Imported Brand
-
Dimensions (L x W x H) (mm):
-
8085*2500*3450mm
-
Cargo Tank Dimension:
-
8085*2500*3450mm
-
Product name:
-
sinotruk howo a7 dump truck 380 hp 25 ton capacity for sale
-
PTO:
-
QH50
-
Front axle:
-
7.5T, ,7500kg
-
Rear axl:
-
16T, STR 2x16000kg
-
Driving type:
-
6x4
-
Farm:
-
850x300(8+7)
-
Color:
-
Optional
-
Cargo box size:
-
5600*2300*1500mm
-
Lifting style:
-
front lifting cylinde
Product Description
sinotruck howo a7 dump truck 380 hp 25 ton capacity for sale
Main Parameters:
| General Specification | ||||
| Model | ZZ3257N3847A | |||
| Series | HOWO | |||
| Wheel Traction / Drive Style | 6X4 | |||
| Full Load Mass Weight | kg | 25000 | ||
| Curb Mass/ Self Weight | kg | 12270 | ||
| Steering Wheel Position | LHD/RHD | LHD (Left Hand Drive) | ||
| Engine | ||||
| Model | WD615.47 | |||
| Brand | SINOTRUK | |||
| Displacement | 9.726L | |||
| Type | In-line, Six-cylinder, Four-stroke, Water-cooled, Direct Injection, Intercooled Turbocharged Diesel Engine | |||
| Engine Classification / Standard | EURO II | |||
| Bore/Stroke | mm | 126/130 | ||
| Rated Horse Power | hp | 371 | ||
| Net Power | KW/rpm | 273KW/2200rpm | ||
| Torque (Nm/rpm): | Nm/rpm | 1500Nm @ 1100-1600rpm | ||
| Clutch & Gear Box Systems | ||||
| Clutch | SINOTRUK's 430 diaphragm spring clutch | |||
| Gear Box | SINOTRUK's HW19710 ,Manual Gearbox | |||
| Gear Speed/Lever | 10 forward/ 2 reverse | |||
| Gear Ratio |
14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34,
1.00, 13.91(R1), 3.18(R2) |
|||
| Axle & Steering | ||||
| Steering Model | ZF8118 | |||
| Front Axle | SINOTRUK's HF9 | |||
| Rear Axle | SINOTRUK's HC16 | |||
| Ratio of Rear Axle | 5.73 | |||
| Loading Capacity per Axle | front | 9000kg | ||
| rear | (2x) 16000kg | |||
| Brake System & Suspension | ||||
| Service Brake | dual circuit compressed air brake | |||
| Auxiliary Brake | engine exhaust valve brake | |||
| Parking Brake (Emergency Brake) | front | spring energy | ||
| rear | compressed air | |||
| Suspension Type | front | 10pcs leaf spring | ||
| rear | 12pcs leaf spring | |||
| Wheels & Tires | ||||
| Wheel Type | stud piloted 10 hole steel disc (20x8.50) | |||
| Number of Tires | 10+1 (spare tire) | |||
| Tire Type/Size | 12.00R20 | |||
| Track | front | 2022mm | ||
| rear | 1830mm | |||
