Quick Details
-
Rated Output Voltage:
-
24.8 V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ROCH
-
Dimensions:
-
295x120x190mm
-
Use:
-
For acid and electrodes
-
Weight (KG):
-
2.7 KG
-
Product name:
-
welding portable machine
-
Function:
-
MMA Inverter IGBT Welding Machine
-
Power Factor:
-
0.93COS
Quick Details
-
Rated Duty Cycle @40°C:
-
40%
-
Rated Input Voltage:
-
220V
-
Max. Load Power Capacity:
-
3.8KVA
-
Rated Output Voltage:
-
24.8 V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ROCH
-
Dimensions:
-
295x120x190mm
-
Use:
-
For acid and electrodes
-
Weight (KG):
-
2.7 KG
-
Product name:
-
welding portable machine
-
Function:
-
MMA Inverter IGBT Welding Machine
-
Power Factor:
-
0.93COS
Products Description
|
ITEM
|
BLADE-120
|
BLADE-140
|
BLADE-160
|
BLADE-180
|
BLADE-200
|
|
Input Power Voltage (V)
|
AC230V
|
AC230V
|
AC230V
|
AC230V
|
AC230V
|
|
Input Power Frequency (Hz)
|
50/60
|
50/60
|
50/60
|
50/60
|
50/60
|
|
Rated Input Capacity (KVA)
|
3.8
|
4.5
|
5.4
|
6.2
|
7.1
|
|
Output Current Range (A)
|
20-120
|
20-140
|
20-160
|
20-180
|
20-200
|
|
No-load Voltage (V)
|
62
|
62
|
62
|
62
|
62
|
|
Rated Duty Cycle (%)
|
40
|
40
|
40
|
40
|
40
|
|
Power Factor (COSØ)
|
0.93
|
0.93
|
0.93
|
0.93
|
0.93
|
|
Protection Grade
|
IP21S
|
IP21S
|
IP21S
|
IP21S
|
IP21S
|
|
Dimensions (mm)
|
295*120*190
|
295*120*190
|
315*120*190
|
335*120*190
|
335*120*190
|
|
Weight (Kg)
|
2.7
|
2.9
|
3.0
|
3.55
|
3.65
|
