Quick Details
-
Product name:
-
21.5 inch CapacitiveTouch Panel
-
Interface:
-
USB
-
Outline Dimension:
-
524(L)*2385(W)*2.8(H)
-
Active Area:
-
347.23*196.54
-
Structure:
-
G+G
-
Touch points:
-
10 point
-
Operating Voltage:
-
5V
-
Humidity:
-
45~85%RH
-
Surface hardness:
-
≥6H
-
Transmission:
-
≥85%
Quick Details
-
Type:
-
Capacitive
-
Brand Name:
-
OEM
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
21.5 inch CapacitiveTouch Panel
-
Interface:
-
USB
-
Outline Dimension:
-
524(L)*2385(W)*2.8(H)
-
Active Area:
-
347.23*196.54
-
Structure:
-
G+G
-
Touch points:
-
10 point
-
Operating Voltage:
-
5V
-
Humidity:
-
45~85%RH
-
Surface hardness:
-
≥6H
-
Transmission:
-
≥85%
| Capacitive Touch Panel |
| Detail Information for Capacitive Touch Panel |
| 21.5 Inch LCD Panel 10 Points Capacitive Touch Screen Monitor | ||
| Item | Contents | Unit |
| Outline Dimension | 524(L)×2385(W)×2.8(H) | ±0.15mm |
| Active Area(L×W) | 948.9×547.78 | ±0.15mm |
| Sensor OD | 496.42×287.43 | ±0.15mm |
| View Area | 496.42×287.43 | ±0.2mm |
| TP Size | 21.5 | inch |
| Interface Type | USB | |
| Operation Temperature | TOPL=-20,TOPH=70 | ℃ |
| Storage Temperature | TSTL=-30,TSTH=80 | ℃ |
| ITO Glass Thickness | 0.7 | mm |
| Glass thickness | 1.8 | mm |
| Resolution | >s | |
| Input force | <10g | |
| Surface Hardness | >6H | |
| Number of Touch Point | 10 Point | |
| Light Transmittance | >85% | |
| Structure | Glass-Glass | |
| Drawing |
| Capatitive Touch Panel Applications |
| Detailed Images |
