Quick Details
-
Protection:
-
Over-discharging, Short Circuit Protection, Over-charging, Low Tension
-
Battery Type:
-
LiFePO4
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM&ODM
-
Model Number:
-
PS01
-
Weight:
-
15kg, 15kg
-
Output Power:
-
1200W
-
Product name:
-
Portable Power Station
-
Shell material:
-
ABS
-
Approx. Dimensions:
-
L368xW200xH275mm
-
Max. Charge Current:
-
10A 300W Max
-
Discharge Cut-off Voltage:
-
20V±0.5V
-
Nominal Voltage:
-
25.6V
-
Minimum Capacity:
-
50Ah
-
Cycle Life:
-
>2000 cycles @0.5C 100%DOD
-
Energy:
-
1280Wh
Quick Details
-
Output Interface:
-
DC, Type C, Four Usb
-
Input Interface:
-
AC
-
Socket Standard:
-
For USA/Canada, Universal
-
Protection:
-
Over-discharging, Short Circuit Protection, Over-charging, Low Tension
-
Battery Type:
-
LiFePO4
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM&ODM
-
Model Number:
-
PS01
-
Weight:
-
15kg, 15kg
-
Output Power:
-
1200W
-
Product name:
-
Portable Power Station
-
Shell material:
-
ABS
-
Approx. Dimensions:
-
L368xW200xH275mm
-
Max. Charge Current:
-
10A 300W Max
-
Discharge Cut-off Voltage:
-
20V±0.5V
-
Nominal Voltage:
-
25.6V
-
Minimum Capacity:
-
50Ah
-
Cycle Life:
-
>2000 cycles @0.5C 100%DOD
-
Energy:
-
1280Wh
Specification
|
item
|
PS01 LiFe1280
|
|
Nominal Voltage
|
25.6V
|
|
Nominal Capacity
|
50Ah
|
|
Minimum Capacity
|
50Ah
|
|
Energy
|
1280Wh
|
|
Cycle Life
|
>2000 cycles @0.5C 100%DOD
|
|
Efficiency of Charge
|
100% @0.5C
|
|
Efficiency of Discharge
|
96~99% @0.5C
|
|
BMS Functions
|
Over charge, over discharge, over current, short circuit and temperature protection
|
|
Charge Voltage
|
28.8-29.2V
|
|
Charge Mode
|
0.2C to 29.2V, then 29.2V,charge current to 0.02C (CC/CV)
|
|
Charge Current
|
5A
|
|
Max. Charge Current
|
10A 300W Max
|
|
Max Continuous Discharge Current
|
50A
|
|
Peak Discharge Current
|
100A 1-3S
|
|
Discharge Cut-off Voltage
|
20V±0.5V
|
|
Shell material
|
ABS+ Aluminum alloy
|
|
Approx. Dimensions
|
L368xW200xH275mm
|
|
Approx. Weight
|
14.3kgs
|
