Low-temperature quick-freezing is the key to long-term high-quality preservation of food. Rapid cooling can make food quickly pass through the ice crystal formation zone, prevent the formation of large ice crystals in food cells, avoid damage to the cell wall,
and perfectly maintain the original quality and taste of the food. The temperature of the quick-freezer is generally -15 ° C ~ -35
° C. It is mainly used for low temperature and rapid freezing of food, medicine, medicine and other items. Cooling down quickly and the preservation effect is good.
- Product Details
- {{item.text}}
Quick Details
-
Cooling Capacity:
-
customized
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CBFI
-
Voltage:
-
380V/3P/50HZ. 220V/3P/60HZ
-
Power:
-
Various(can be customized)
-
Dimension(L*W*H):
-
customized
-
Weight:
-
1000 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Cold room panel:
-
color plate,stainless steel, galvanizde sheet
-
cooling system:
-
air cooling or water cooling
-
Container size:
-
depends on your choice
-
Functions:
-
fresh-keeping, frozen food storage, quick-freezing
-
Electrical components:
-
LG
-
Refrigerant:
-
R22/R404a
-
Panel thickness:
-
100/120/150/200mm or customized
-
Keywords:
-
blast freezer
-
Certification:
-
ISO9001, CE, ISO4001
Quick Details
-
Temperature:
-
-45℃~20℃ (it is adjustable)
-
Compressor brand:
-
Bristol, Bitzer, Frascold
-
Panel Thickness:
-
customized
-
Cooling Capacity:
-
customized
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CBFI
-
Voltage:
-
380V/3P/50HZ. 220V/3P/60HZ
-
Power:
-
Various(can be customized)
-
Dimension(L*W*H):
-
customized
-
Weight:
-
1000 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Cold room panel:
-
color plate,stainless steel, galvanizde sheet
-
cooling system:
-
air cooling or water cooling
-
Container size:
-
depends on your choice
-
Functions:
-
fresh-keeping, frozen food storage, quick-freezing
-
Electrical components:
-
LG
-
Refrigerant:
-
R22/R404a
-
Panel thickness:
-
100/120/150/200mm or customized
-
Keywords:
-
blast freezer
-
Certification:
-
ISO9001, CE, ISO4001
Product Overview
Product Explanation
Product Features
1. Our frame is made of high-strength SUS304 stainless steel and is designed to provide a durable, long-lasting, rust-free life while accommodating valuable components.
2. The cold room has a wide range of application such as fruit, vegetable, fish, meat preservation. It proves to be the best food preservation solution with its fast freezing time and great thermal installation performance.
3. It is a reliable and energy-efficient machine that is guaranteed with a long service life and low operating and maintenance costs. Also, it is worth mentioning that it highly complies with refrigerant and energy regulations.
4. Save installation and maintenance costs. The cold room that we provide can offer the best protection for perishable goods with efficient operation and long service life.
Main Components
Wall-mounted Intelligent
Cold Room Unit
This unit is installed on the wall of the cold room. We provide wall panel with window for the installation. Thus, it is easy to install. There is no need for welding.
Separated Cold Room Unit
The air cooler is seperated from the other parts of the unit. The connection is using copper connector, like the one in air conditioner. So the installation is as easy as installing an air conditioner.
Pressure Monitoring
Good quality pressure gauge is used for pressure monitoring. And pressure protector is used to avoid pressure damage.
Bitzer Screw Compressor
Cold Room Unit
Bitzer screw compressor can be used at various temperatures, has stronger environmental adaptability. It is more energy efficient when it achieves the same cooling capacity. Its price is even higher.
Copeland Paralleled Cold Room Unit
Copeland is from US, the quality is also good. The paralleled system is able to operate when one of the compressors is not working. This allows the cold storage running without goods loss.
Bitzer Paralleled
Cold Room Unit
This unit combines the good quality of Bitzer and stable operation of paralleled system. It is high efficient, stable and reliable.
There are three kinds of surface material for chosen, stainless steel, aluminium plate and color steel. The characters of the three plates are different. Our design engineer provide different solutions for different requirements. The thickness of the plate could be customized. We also provide normal standard.
Product Parameters
|
panels thickness (mm)
|
temperature gap between internal- external environment
|
height of wall panel (max)
|
roof length (max)
|
applicable temperature for cold room (℃)
|
||||
|
mm
|
℃
|
m
|
m
|
25 20 15 10 5 0 -5 -10 -15 -20 -25 -30 -40 -45 -50 -55
|
||||
|
50
|
30
|
3.5
|
2.4
|
|
||||
|
75
|
40
|
4.5
|
3.8
|
|
||||
|
100
|
50
|
5
|
4.5
|
|
||||
|
120
|
60
|
5.5
|
6
|
|
||||
|
150
|
70
|
6
|
6.5
|
|
||||
|
200
|
90
|
7
|
7.6
|
|
||||
|
㎡: if there is pressure gap between internal-external environment without wind load, over-length or wind-load need to set steel wall beam.
|
|
|
|
|
||||
|
tips: the data above is figured out according to 8-10 W / ㎡ heat flux.
|
|
|
|
|
||||
