Quick Details
-
Chassis Brand:
-
FOTON
-
Driving Type:
-
LHD RHD 4*2
-
Engine:
-
4A1-68C40
-
Engine power:
-
68HP
-
Garbage box Volume:
-
3cbm, 5cbm
-
Max speed:
-
90 Km/h
-
Loading capacity:
-
3000kg
-
WheelBase:
-
2800mm
Quick Details
-
Place of Origin:
-
Hubei, China
-
Product name:
-
Small swing arm garbage truck
-
Color:
-
Blue, White (Customizable)
-
Chassis Brand:
-
FOTON
-
Driving Type:
-
LHD RHD 4*2
-
Engine:
-
4A1-68C40
-
Engine power:
-
68HP
-
Garbage box Volume:
-
3cbm, 5cbm
-
Max speed:
-
90 Km/h
-
Loading capacity:
-
3000kg
-
WheelBase:
-
2800mm
Applications : the swing arm garbage truck is a cost competitive option for rural or suburb garbage collecting. It can be also used in collecting contruction wastes.
Truck Chassis : Foton, JAC, DFAC etc. (Other brand chassis available)
Dump box/Dustbin Capacity : 10cbm ~ 15cbm, max loading weight 3000kg
Main Market : our garbage truck are widely sold in Africa, S. America, Middle East and Asian countries.
Below photo includes our garbage trucks, and spec is a 3cbm capacity model using Foton chassis for reference. We also provide other types of garbage trucks. Please contact us (mobile/whatsapp/skype +86 17671789786) to learn more details before placing order.
| PARAMETER | DATA |
| Overall dimension | 4880*1620*2020 MM |
| Max Loading capacity | 3000 KG |
| Max speed | 90 |
| Chassis model | Foton BJ1042V9JA5-X2 |
| Wheelbase | 2800 mm |
| Tire Specification | 6.00-13 8PR,6.00-14 10PR |
| Engine Horse power | 68 |
| Emission Standard | EURO III |
| Dustbin | Carbon Steel. Shape of dustbin customizable |
| Basic configuration | Hydraulic system, operating system, lifting system, oil tank, cabinet door pendulum, hanging barrels institutions etc. |
