Quick Details
-
Maximum Power:
-
30KW
-
Connector:
-
CCS2/CCS2/CHADEMO
-
Cable Length:
-
5m (16.4ft)
-
Enclosure:
-
IP55/IK10
-
Operating Temperature:
-
-25°C +55°C
-
Mounting:
-
Floor Mounted
-
Network connection:
-
4G/Ethernet
-
Warranty:
-
12 months
-
OCPP:
-
OCPP1.6J
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
BDC-30
-
Brand Name:
-
ZJBENY
-
Maximum Power:
-
30KW
-
Connector:
-
CCS2/CCS2/CHADEMO
-
Cable Length:
-
5m (16.4ft)
-
Enclosure:
-
IP55/IK10
-
Operating Temperature:
-
-25°C +55°C
-
Mounting:
-
Floor Mounted
-
Network connection:
-
4G/Ethernet
-
Warranty:
-
12 months
-
OCPP:
-
OCPP1.6J
Product Paramenters
|
Models
|
BDC-30
|
BDC-60
|
BDC-90
|
BDC-120
|
BDC-150
|
BDC-180
|
BDC-240
|
||||||
|
Connectors
|
CCS1/CCS2/CHADEMO
|
|
|
|
|
|
|
||||||
|
Number of plugs
|
DC*1
|
DC*1
|
DC*1
|
DC*1
|
DC*1
|
DC*1
|
DC*1
|
||||||
|
DC output power
|
30kw
|
60kw
|
90kw
|
120kw
|
150kw
|
180kw
|
240kw
|
||||||
|
AC input voltage
|
AC380V±15%,3P+N+PEAC
|
|
|
|
|
|
|
||||||
|
AC input frequency
|
50Hz/60Hz
|
|
|
|
|
|
|
||||||
|
Output voltage range
|
CCS1 or CCS2:0~250A 150VDC-1000V or CHADEMO 0~133A 150V-500V
|
|
|
|
|
|
|
||||||
|
Efficiency
|
≥94%
|
≥94%
|
≥94%
|
≥94%
|
≥94%
|
≥94%
|
≥94%
|
||||||
|
Consumption
|
≤2W
|
≤2W
|
≤2W
|
≤2W
|
≤2W
|
≤2W
|
≤2W
|
||||||
|
IP Rating
|
IP55
|
|
|
|
|
|
|
||||||
|
Warranty
|
12 Months
|
|
|
|
|
|
|
||||||
|
Standard
|
IEC61851-1, IEC61851-23
|
|
|
|
|
|
|
||||||
|
Power factor
|
≥0.99(load:100%
|
|
|
|
|
|
|
||||||
|
Connectivity authorization
|
RFID,APP
|
|
|
|
|
|
|
||||||
|
Communiction
|
OCPP 1.6
|
OCPP 1.6
|
OCPP 1.6
|
OCPP 1.6
|
OCPP 1.6
|
OCPP 1.6
|
OCPP1.6
|
||||||
|
Cable Length
|
5 M
|
5 M
|
5 M
|
5 M
|
5 M
|
5 M
|
5 M
|
||||||
|
Network
|
Ethernet/4G
|
|
|
|
|
|
|
||||||
|
Cooling
|
Forced-air cooling
|
|
|
|
|
|
|
||||||
|
Working Temperature
|
-30℃~+55℃
|
|
|
|
|
|
|
||||||
|
Screen
|
9.1inch LCD screen/LED light
|
|
|
|
|
|
|
||||||
|
Function
|
Emergency Stop Button,LED Indicator,RFID,TouchScreen
|
|
|
|
|
|
|
||||||
|
Shell Material
|
Carbon Steel
|
|
|
|
|
|
|
||||||
|
Weight
|
≤350KG
|
≤350KG
|
≤350KG
|
≤350KG
|
≤350KG
|
≤350KG
|
≤350KG
|
||||||
|
Dimension
|
800*800*2000(L*W*T)
|
|
|
|
|
|
|
||||||
