Quick Details
-
Place of Origin:
-
Fujian, China
-
Appearance:
-
Black Powder
-
Application:
-
Lithium Ion Battery Materials
-
Brand Name:
-
TOB
-
Model Number:
-
T-NCM-111/532/622/811
-
Name:
-
lithium nickel manganese cobalt oxide
-
Type:
-
Lithium Ion Battery Cathode Material
-
D(50):
-
9-12
-
Related industry:
-
Lithium ion battery
-
Color:
-
Black
-
Standard Packing:
-
500g/bag
-
Custom packaging:
-
100g/bag,250g/bag/1000g/bag
-
MOQ:
-
100g
Quick Details
-
CAS No.:
-
346417-97-8
-
Purity:
-
N/A
-
Other Names:
-
Lithium Nickel Manganese Cobalt Oxide
-
Place of Origin:
-
Fujian, China
-
Appearance:
-
Black Powder
-
Application:
-
Lithium Ion Battery Materials
-
Brand Name:
-
TOB
-
Model Number:
-
T-NCM-111/532/622/811
-
Name:
-
lithium nickel manganese cobalt oxide
-
Type:
-
Lithium Ion Battery Cathode Material
-
D(50):
-
9-12
-
Related industry:
-
Lithium ion battery
-
Color:
-
Black
-
Standard Packing:
-
500g/bag
-
Custom packaging:
-
100g/bag,250g/bag/1000g/bag
-
MOQ:
-
100g
NCM 111 622 532 811 NMC Lithium Nickel Manganese Cobalt Oxide For Lithium Ion Battery
Lithium-ion battery cathode ternary material, used in various liquid lithium-ion batteries, flexible packaging batteries and polymer lithium-ion batteries.
Product model: T-NCM-111
Physical and chemical indicators
|
Item |
Standard requirement |
Test method |
|
|
Main content(%) |
Li |
7.3~7.9 |
ICP Test method |
|
Ni |
20.6 ±1.00 |
ICP Test method |
|
|
Co |
21.0±1.00 |
ICP Test method |
|
|
Mn |
16.60 ± 1.00 |
ICP Test method |
|
|
Impurity element(μg/g) |
Fe |
≤30 |
ICP Test method |
|
Cu |
≤20 |
ICP Test method |
|
|
Zn |
≤20 |
ICP Test method |
|
|
S |
≤3500 |
ICP Test method |
|
|
Particle size distribution(μm) |
D10 |
≥2.5 |
Laser particle size detector |
|
D50 |
7.5±1.0 |
Laser particle size detector |
|
|
D90 |
≤16 |
Laser particle size detector |
|
|
Specific surface area(m 2 /g) |
0.25~0.45 |
Gas adsorption assay |
|
|
Tap density(g/cm 3 ) |
≤2.20 |
Tap density tester |
|
|
Water content(μg/g) |
≤500 |
Karl Fischer Method |
|
|
Li Dissolution amount |
≤0.25 |
785DMP TITRINO automatic potential titrator |
|
|
PH value |
≤12.0 |
PH value |
|
|
Exterior |
The black solid powder has no impurities, no agglomeration, no agglomeration and no larger particles |
||
Product model: T-NCM-532
Chemical index
|
Unit |
Standard |
Reference |
The analytical methods |
|
|
Li |
% |
7.0~8 |
7.1 |
ICP |
|
Ni+Co+Mn |
% |
57~62 |
59.2 |
ICP |
|
Ca |
% |
≤0.0200 |
0.0035 |
ICP |
|
Cu |
% |
≤0.0050 |
0.0002 |
ICP |
|
Fe |
% |
≤0.0010 |
0.0003 |
ICP |
|
Na |
% |
≤0.0300 |
0.0188 |
ICP |
Product model: T-NCM-622
This type of NMC 622 is gray-black powder without caking.
Product model: T-NCM-811
This product can be used as a cathode material in the manufacture of lithium ion secondary batteries.
The full battery design capacity of this product with graphite negative electrode: 188 ~ 190mAh / g (0.5C, 4.2V-3.0V) (affected by the customer's process, the data has a certain degree of fluctuation)
It is recommended to bake the material at 120 ℃ for 6h before mixing.
Processing design compaction 3.30 ~ 3.50g / cm3 (Affected by the customer's process, the data has a certain degree of fluctuation).
According to the performance requirements, choose an appropriate electrolyte that matches the high nickel nickel-cobalt manganese oxide.
