Quick Details
-
Warranty:
-
30 years warranty
-
Brand Name:
-
Bluesun Solar
-
Model Number:
-
BSM440M10-54HNH
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1722*1134*30mm
-
Color:
-
Balck
-
Cell Type:
-
108 (6*18)
-
Weight:
-
21kg
-
Cable Length:
-
+400mm, -200mm or ± 1200mm, length can be customized
-
No. of Bypass Diodes:
-
3
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP68
-
Operating Temperature:
-
-40°C~ +85°C
-
Static Loading:
-
Snow Loading: 5400Pa/ Wind Loading: 2400Pa
-
Certificate:
-
CE TUV PID
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Bifacial, All Black, N-TYPE, TOPCON, Mono
-
Panel Efficiency:
-
22.53
-
Warranty:
-
30 years warranty
-
Brand Name:
-
Bluesun Solar
-
Model Number:
-
BSM440M10-54HNH
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1722*1134*30mm
-
Color:
-
Balck
-
Cell Type:
-
108 (6*18)
-
Weight:
-
21kg
-
Cable Length:
-
+400mm, -200mm or ± 1200mm, length can be customized
-
No. of Bypass Diodes:
-
3
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP68
-
Operating Temperature:
-
-40°C~ +85°C
-
Static Loading:
-
Snow Loading: 5400Pa/ Wind Loading: 2400Pa
-
Certificate:
-
CE TUV PID
Product Description
|
SPECIFICATIONS
|
|
|
|
|
|
|||||
|
Module Type
|
BSM425M10-54HNH
|
BSM430M10-54HNH
|
BSM435M10-54HNH
|
BSM440M10-54HNH
|
BSM445M10-54HNH
|
|||||
|
Maximum Power (Pmax/W)
|
STC
|
STC
|
STC
|
STC
|
STC
|
|||||
|
|
425
|
430
|
435
|
440
|
445
|
|||||
|
Operating Voltage (Vmp/V)
|
31.69
|
31.87
|
32.06
|
32.25
|
32.44
|
|||||
|
Operating Current (Imp/A)
|
13.42
|
13.5
|
13.58
|
13.66
|
13.74
|
|||||
|
Open-Circuit Voltage (Voc/V)
|
38.29
|
38.48
|
38.67
|
38.86
|
39.05
|
|||||
|
Short-Circuit Current (Isc/A)
|
14.16
|
14.24
|
14.32
|
14.40
|
14.48
|
|||||
|
Module Efficiency
|
21.76
|
22.02
|
22.28
|
22.53
|
22.79
|
|||||
|
STC: Irradiance 1000W/m² , Cell Temperature 25°C, Air Mass AM1.5
|
|
|
|
|
|
|||||
