Quick Details
-
Power:
-
15-70Kw depends on size
-
Dimension(L*W*H):
-
Customize
-
Weight:
-
3850 KG
-
Customize according to your request:
-
YES
-
Raw material:
-
SUS304 316 Mirror finish Red Copper clading
-
Brewhouse type:
-
2/3/4/5 vessel
-
Mashing method:
-
Infusion/Decoction
-
Heating method:
-
Electric/Steam/Direct fired
-
Insulation material:
-
Polyurethane/Rockwool
-
Inner Polishing Precision:
-
0.2-0.4 Micrometer
-
Controlling System:
-
PID/PLC
-
Application:
-
best beer brewing equipment in restaurant hotel
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Tiantai OEM
-
Voltage:
-
220v/380v/400v/415v
-
Power:
-
15-70Kw depends on size
-
Dimension(L*W*H):
-
Customize
-
Weight:
-
3850 KG
-
Customize according to your request:
-
YES
-
Raw material:
-
SUS304 316 Mirror finish Red Copper clading
-
Brewhouse type:
-
2/3/4/5 vessel
-
Mashing method:
-
Infusion/Decoction
-
Heating method:
-
Electric/Steam/Direct fired
-
Insulation material:
-
Polyurethane/Rockwool
-
Inner Polishing Precision:
-
0.2-0.4 Micrometer
-
Controlling System:
-
PID/PLC
-
Application:
-
best beer brewing equipment in restaurant hotel
5000l craft beer brewing equipment for sale
Welcome to checked "craft beer brewing equipment for sale" in detail. 5 000L craft beer brewing equipment is usually used in middle size of brewery factory. It is also a popular system choice in expanding project. 5 vessel usually means mash tun+lauter tun+buffer tank+kettle tun+whirlpool tun+hot liquor tank. Except for 5 vessel brewhoues, 2/3/4 vessel brewhouse are also as optional. For more details in this system, please check product description. craft beer brewing equipment for sale
|
|
Grain Miller unit |
2000-2500KG/HR |
1set |
|
Brewhouse unit |
MT+LT+BT+KT+WT+HLT (Or customize) |
1unit |
|
|
Heating: Steam |
Optional |
||
|
Fermenter |
5000L or 10000L(more economical) |
4sets |
|
|
Brite Beer Tank |
5000L or 10000L |
1set |
|
|
Glycol Chilling Unit |
10000L Glycol Water tank |
1set |
|
|
8hp Chiller |
2sets |
||
|
Glycol pipeline |
1set |
||
|
Control System |
PID |
1set |
|
|
Cleaning Unit |
500L CIP |
1set |
Welcome to click following link to get a quotation with detailed price. Will reply you within 12 hours.
***5000Liter/batch, first batch takes about 8 hours, and 3 batches of 16 hours are allowed;
***Steam heated, high thermal efficiency, gentle for wort; Electric or direct fire heating available;
***All certificated 304 stainless steel, easy to clean; Copper cladding for special environments such as bars;
***The wort cooled by tap water and -5 ºC ice water to cool in two stages, Single stage available;
Mashing heating and fermentation cooling automatically controlled, and manual control switched at any time;
***Fermenter can be top or side manway
***Manual valve control, humanized operation, low equipment investment cost, high cost performance; PLC automatic control for upgrade
1. One Stop Service from malt to beer
2. Design Customization: Tanks structure, pipeline, installation
3. 5 Years Warranty for tanks, free delivery for broken accessory within warranty
4. With ISO TUV SGS certificate, the product meets the GB/CE/PED/ASME standard
5. Local service in EUROPE, AUSTRALIA ETC
6. More than 1100+ global users 5000l craft beer brewing equipment for sale
| Part 1: Grain Miller | |
|
Capacity |
2000-2500kg/hr |
| Function | Curshing malt for mashing |
| Material | Carbon steel or stainless steel |
|
Crushing Particle Size |
Adjustable |
|
Wheels |
Optional 5000l craft beer brewing equipment for sale |
|
Part 2: 5 vessel brewhouse |
|
|
Capacity |
5000L brewhouse tanks and 10000L hot liquor tank |
|
Brewhouse structure |
Mash tun+lauter tun+buffer tank+kettle tun+whirlpool tun+hot water tun |
|
Heating method |
Steam heating( Boiler/ steam generator is necessary) |
|
Direct fire heating is optional |
|
|
Pump |
4 set wort pumps+1 set hot water pump |
|
Platform |
Included 5000l craft beer brewing equipment for sale |
| Heat exchanger | Double stage brand |
|
Customization |
Customize tank structure, pipe flowing, installation and others |
| Part 3: Fermentation Tank | |
| Capacity | 5000L fermenter or 10000L fermenter |
| Size | Φ1760mmx4600mm or Φ1960mmx5700mm(Customized ) |
| Function | Beer Fermenting/first fermentation |
| Structure |
Double wall with jacket and insulation |
|
Manway Site |
Top or Side, optional |
|
Cooling medium |
Glycol water |
|
Fermenting pressure |
2bar or 3bar |
|
Spunding valve |
Available for adjusting fermenting pressure inside tank |
| Part 4: Bright Beer Tank | |
| Capacity | 5000L Bright beer tank or 10000L bright beer tank |
| Size | Customized 5000l craft beer brewing equipment for sale |
|
Function |
Beer maturing/Secondary fermentation |
|
Fermenting Pressure |
2bar or 3bar |
|
Part 5: Glycol Chilling System |
|
| Configuration |
Matched glycol water tank+ chiller+pipeline |
|
Control type |
Automatic control |
| Installation site | Outdoor 5000l craft beer brewing equipment for sale |
|
Pipeline |
PPR; PEX or Stainless Steel |
|
Part 6: Controlling System |
|
| Cabinet Material | Anti-power Plastic painting or Stainless Steel cover |
| Assembling Style | Floor/Wall hanging |
|
Certificate |
CE certificated |
| Control Type | PID Control; PLC automated control for optional |
|
Part 7: CIP Cleaning System |
|
|
Capacity |
500L |
|
Structure |
Two tanks with cart and wheels |
|
VFD |
Yes |
|
Independent Controller |
Yes |
