- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
C120
-
Input voltage and current:
-
100-240V/2.5A
-
output voltage and current:
-
24V/5A
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
24V 5A Desktop SLA Battery Charger
-
Input:
-
100-240VAC 50/60HZ
-
Output voltage:
-
24V
-
Output current:
-
5A
-
Output power:
-
120W
-
Charging efficiency:
-
89%(full load)
-
Standard:
-
EN60335
-
AC plug:
-
eu, uk au, us
-
Logo:
-
Laser
-
Application:
-
Electric Scooter, Hoverboard
Quick Details
-
Type:
-
Power Supply Adapter, Desktop Charger
-
Port:
-
DC
-
Brand Name:
-
CB
-
Model Number:
-
C120
-
Input voltage and current:
-
100-240V/2.5A
-
output voltage and current:
-
24V/5A
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
24V 5A Desktop SLA Battery Charger
-
Input:
-
100-240VAC 50/60HZ
-
Output voltage:
-
24V
-
Output current:
-
5A
-
Output power:
-
120W
-
Charging efficiency:
-
89%(full load)
-
Standard:
-
EN60335
-
AC plug:
-
eu, uk au, us
-
Logo:
-
Laser
-
Application:
-
Electric Scooter, Hoverboard
Supply 24V 5A Desktop SLA Battery Charger 24V Lead Acid Battery Chargers For Scooters, wheelchairs, electric vehicles Charging
|
Product Name |
24V 5A Desktop SLA Battery Charger | |
| Models | 120W Series | |
| INPUT | 100-240VAC 50/60Hz 2.5A | |
| Output | 24V 5A 120W | |
|
Charging Satus |
Charing mod | CC/CV - float charge |
| Float Charge | 500-800mA (customized) | |
| Charing Time | (Battery capacity/the charging current) x1.2 | |
| Safety&EMC | Safety Standard | ETL1310, EN60335 |
| Safety Approvals | CUL, ETL, CE, FCC, RoHS, UKCA, PSE, CB, SAA, KC etc. | |
| EMC Stardard |
EMC EMISSION: EN55032 class B (CISPR32), EN61000-3-2,-3, EAC TP TC 020
EMC IMMUNITY: EN61000-4-2,3,4,5,6,8,11, EN55024; light industry level, criteria A, EAC TP TC 020
|
|
| MTBF | 80K hrs min. MIL-HDBK-217F (25℃) | |
Features:
Input inlet: IEC320-C8, C6, C14 (optional)
Universal AC plugs: US/EU/UK/AUS/CN/JP/KR and more
LED indicating: Charging in red, fully charged in green.
Common models for Li-ion battery charger:
8.4V/12.6V/16.8V/25.2V/29.4V/42V/54.6V @1.5A-8.3A, 120W max
Common models for LifePO4 battery charger:
7.2V/14.6V/29.2V/58.4V @1.5A-8.3A, 120W max
Common models for SLA battery charger:
6V/12V/24V/36V/48V @1.5A-8A, 120W max
Mechanical:
Size: 139 x 61 x 35.5mm (L x W x H)
N.W.: 360g
Packing: 40pcs/16.5kg/0.045CBM/ctn
Case Style: Desktop type (see the picture and drawing).
Output cord: 1.2m/1.5m/1.8m or customized length.
Connector: 5.5x2.1mm, XRL, RCA, Clam chip, Crocodile chip or others.
Applications:
widely used in electric bicycle chargers, electric motorcycle chargers, electric scooter chargers, balance car chargers, unmanned aircraft chargers, smart home chargers, garden tool chargers, medical equipment and Communication equipment, digital products, computers and peripheral equipment, etc.
