Quick Details
-
Brand Name:
-
Shengda
-
Model Number:
-
SDLD-50
-
Product Name:
-
DN50 RS485 electromagnetic water flow meter price for sewage
-
keyword:
-
RS485 electromagnetic flow meter price
-
size:
-
DN15~DN2000mm
-
communication:
-
RS485, RS232, Modbus, Hart, Profibus-DP
-
power supply:
-
220V/DC24V/DC3.6V
-
signal output:
-
4~20mA,0~5000Hz
-
medium conductivity:
-
more than 5us/cm
-
protection grade:
-
IP65
-
color:
-
blue, grey or customized
-
connection:
-
flange
Quick Details
-
Type:
-
Variable Area Water Flowmeters
-
Warranty:
-
1 year
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Shengda
-
Model Number:
-
SDLD-50
-
Product Name:
-
DN50 RS485 electromagnetic water flow meter price for sewage
-
keyword:
-
RS485 electromagnetic flow meter price
-
size:
-
DN15~DN2000mm
-
communication:
-
RS485, RS232, Modbus, Hart, Profibus-DP
-
power supply:
-
220V/DC24V/DC3.6V
-
signal output:
-
4~20mA,0~5000Hz
-
medium conductivity:
-
more than 5us/cm
-
protection grade:
-
IP65
-
color:
-
blue, grey or customized
-
connection:
-
flange
DN50 RS485 electromagnetic water flow meter price for sewage
DN50 RS485 electromagnetic water flow meter price for sewage
Working principle
Electromagnetic flow meters are flowmeters that measure flow according to Faraday's law of electromagnetic induction. Electromagnetic flowmeters have the advantage of minimal pressure loss and a large range of measurable flow rates. The ratio of the maximum flow rate to the minimum flow rate is generally more than 20:1. The applicable industrial tube diameter is wide, up to 3 meters. The output signal and the measured flow rate are linear, and the accuracy is high. The conductivity can be measured ≥5μs/cm. Acid, alkali, salt solution, water, sewage, corrosive liquids, and fluid flow of mud, pulp, pulp, etc. However, it cannot measure the flow of gas, steam, and pure water.
DN50 RS485 electromagnetic water flow meter price for sewage
Quick specifications:
| Place of origin | Henan, China (Mainland) |
| Model No. | SDLD |
| Medium | All kinds of conductive liquids |
| Liner | Rubber, PTFE, F46, ceramic, etc. |
| Connection | Flange type |
| Output | 4-20mA/RS485/HART/PROFIBUS DP |
| Power supply | 220VAC/24VDC/3.6V |
| Ambient temperature | -25℃~60℃ |
| Protection grade | IP65/IP67/IP68 (optional) |
| Accuracy | 0.5%, 0.3%, 0.2% |
| Material | CS, SS, etc. |
| Flange standard | GB/DIN/ANSI/JIS/etc. |
DN50 RS485 electromagnetic water flow meter price for sewage
DN50 RS485 electromagnetic water flow meter price for sewage
DN50 RS485 electromagnetic water flow meter price for sewage
