Quick Details
-
Graphic Format Supported:
-
AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Myoung
-
Dimension(L*W*H):
-
3941*2082*1200mm
-
Weight (KG):
-
1100 KG
-
Laser Power:
-
150W Single Tube, 280W Folding Tube, 300W/400W Combined Beam Tube
-
Cutting Thickness(150W):
-
20mm Acrylic, 15mm Board/deck, 10mm MDF
-
Cutting Thickness(300W):
-
40mm Acrylic, 20mm Board/deck, 15mm MDF
-
Power Supply:
-
220V,50HZ/60HZ
-
Machine Tool:
-
Five-axis Gantry Milling Finishing
-
Transmission System:
-
Ball Screw + Alumnium Gantry
-
Servo System:
-
Control Motor
-
Optical Path:
-
Five Reflective Lens
-
Cutting Head:
-
Automatic
-
Cooling System:
-
Industrial Chiller
Quick Details
-
Engraving Area:
-
1300*2500mm
-
Laser Type:
-
CO2
-
Engraving Speed:
-
0-1200mm/s
-
Graphic Format Supported:
-
AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Myoung
-
Dimension(L*W*H):
-
3941*2082*1200mm
-
Weight (KG):
-
1100 KG
-
Laser Power:
-
150W Single Tube, 280W Folding Tube, 300W/400W Combined Beam Tube
-
Cutting Thickness(150W):
-
20mm Acrylic, 15mm Board/deck, 10mm MDF
-
Cutting Thickness(300W):
-
40mm Acrylic, 20mm Board/deck, 15mm MDF
-
Power Supply:
-
220V,50HZ/60HZ
-
Machine Tool:
-
Five-axis Gantry Milling Finishing
-
Transmission System:
-
Ball Screw + Alumnium Gantry
-
Servo System:
-
Control Motor
-
Optical Path:
-
Five Reflective Lens
-
Cutting Head:
-
Automatic
-
Cooling System:
-
Industrial Chiller
Products Description
Product Paramenters
To learn more about the rule parameters or to customize the size of the machine
Please contact the online customer service
|
Model
|
M1325
|
M1530
|
|
|
Max Working Area
|
1300x2500mm
|
1525x3040mm
|
|
|
Laser Power
|
150W Single Tube, 280W Folding Tube, 300W/400W Combined Beam Tube
|
|
|
|
Cutting Thickness(150W)
|
20mm Acrylic, 15mm Board/deck, 10mm MDF
|
|
|
|
Cutting Thickness(300W)
|
40mm Acrylic, 20mm Board/deck, 15mm MDF
|
|
|
|
Power Supply
|
220V,50HZ/60HZ
|
|
|
|
Weight
|
1100kg
|
1300kg
|
|
|
Machine Size
|
3941x2082x1200mm
|
4541x2382x1200mm
|
|
|
Servo System
|
XY Yakotec Control Motor & Drive Or Japan Yaskawa Motor & Drive (Optional)
|
|
|
Application Materials
It is suitable for engraving cutting wood, plastic, MDF, glass, leather, rubber, laminate and other
non-metallic materials.(
For more materials and finished products, please contact online customer service
)
Product Advantages
Industrial aerospace extruded aluminium beams are characterised by their low density, toughness and corrosion resistance, allowing machines to run faster.
X-axis with high precision ball screw construction. The double guide rails and servo motor drive system make the drive more efficient. The long service life of the screw due to low friction also reduces later maintenance.
Patented follow-up smoke extraction system and reaction smoke extraction system. The system's barrier design and U-shape allows 95% of the smoke to be exhausted, protecting the environment ano the human body.
Innovative application of the double drive rack and pinion Industria drive system with gearbox + guideway. The rack and pinion drive construction allows for a large load carrying capacity of the machine. lt also enables transmission speeds of up to 2 m/S and transmission accuracy of 0.1 mm.
The machine is welded with metal 100mm square tubes and the bed has a long itudinal main beam of square tubes.The tool holders are polished with high precision to ensure that the deviation in working accuracy is within 1%.
Humanized circuit wiring way, when the machine malfunction, you can quickly find the problem and repair. Ensure the productivity remains unchanged.
Real Photograph
For more information about machine configurations, please contact online customer service.
Enterprise information
More machine types
Other models of co2 laser cutting and engraving machines can be found by clicking on the pictures for details.
For more questions, please consult online customer service.
FAQ
Q1: What materials is this machine suitable for?
Mainly used for laser cutting of acrylic, wood, PVC, MDF, fabric, cloth and other materials
.
Q2: lf we don't know how to use the machine, do you have teaching ortraining class for us?
Yes. We have fully customers service training video for your kindlyreference, attached will also be machine cutting parameters and worknotes. lfyou still confused about it, please contact our sales and we willhelp you any mins as your service.
Q3: How long is the delivery time?
For standard machines, it would be 1-2 weeks; For non-standard machinesand customized machines according to clien's specific requirements, itwould be 3-4 weeks.
Q4: How do you guarantee the quality of the machine?
The whole production will be under regular inspection andstrict quality control. Myoung machines will be tested before shipmentwith our fully quality control system. CE Certificate qualified, meetEuropean and American standard.ean and American standard.
Q5: Do you arrange shipment for the machines?
Yes, any shipping terms could be negotiable. For EXW price,clients needto arrange shipment by themselves or their agents.
