Quick Details
-
Dimension(L*W*H):
-
1570*1770*1430mm
-
Weight:
-
920 KG
-
Marketing Type:
-
New Product 2024
-
Product name:
-
Excavator Tree shear
-
Material:
-
Q460NM360/400 HARDOX450/500
-
Model:
-
JSW200
-
Max diameter of the tree:
-
500MM
-
Clamp max opening:
-
995MM
-
Demensions:
-
1570*1770* 1405mm
-
Applicable excavator:
-
20-30Texcavator
-
Color:
-
Customers' Requirement
-
Working type:
-
Working
-
OEM:
-
supported
Quick Details
-
Use:
-
Cutting trees
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
MONDE
-
Dimension(L*W*H):
-
1570*1770*1430mm
-
Weight:
-
920 KG
-
Marketing Type:
-
New Product 2024
-
Product name:
-
Excavator Tree shear
-
Material:
-
Q460NM360/400 HARDOX450/500
-
Model:
-
JSW200
-
Max diameter of the tree:
-
500MM
-
Clamp max opening:
-
995MM
-
Demensions:
-
1570*1770* 1405mm
-
Applicable excavator:
-
20-30Texcavator
-
Color:
-
Customers' Requirement
-
Working type:
-
Working
-
OEM:
-
supported
Forestry Use Excavator Attachment Firewood Cutting Machine Rotating Tree Shear
Product Description
Why to use MONDE tree shear?
Simply, why use chainsaws if you can do the job cheaper, quicker and safer working from the warm and comfortable cab of a machine in almost all weather conditions? Tree Shears have become the most cost-effective and safest way to fell trees since Shandong Mingde Machinery Co., LTD introduced them to the China in 2005.
|
Model
|
|
JSM30
|
JSM50
|
JSM80
|
JSM120
|
JSM200
|
|
|
Preset Pressure(mpa)
|
|
25
|
25
|
25
|
25
|
25
|
|
|
Max Pressure(mpa)
|
|
31.5
|
31.5
|
31.5
|
31.5
|
31.5
|
|
|
Max Diameter Of The Tree(mm)
|
|
120
|
200
|
300
|
350
|
500
|
|
|
Clamp Max Opening(mm)
|
|
400
|
564
|
607
|
847
|
995
|
|
|
Weight(kg)
|
|
160
|
265
|
420
|
1160
|
1568
|
|
|
Dimensions
|
Length(mm)
|
750
|
950
|
1150
|
1595
|
1768
|
|
|
|
Width(mm)
|
450
|
690
|
810
|
1245
|
1405
|
|
|
|
Height(mm)
|
430
|
530
|
615
|
820
|
825
|
|
|
Applicable Excavators(t)
|
|
2-3
|
4-6
|
8-10
|
12-18
|
20-30
|
|
MONDE Tree Shear got started from an own need, and it was developed to work efficiently even in the most challenging work conditions. This to be possible, the product needed to be easy to use, reliable and productive. Thorough designing and engineering resulted in a MONDE Tree Shear which was efficient and easy to operate.
The simple cutting cycle involves:
1) Opening the grab,
2) Lining up a tree,
3) Pushing the blade in to the tree whilst closing the grab
4) Placing the cut tree down to one side
Product Details
MONDE excavator tree shear range are Heavy Duty, professional work tools and are primarily available for use on any excavator between 2-30 tonnes, as well as being adaptable to fit on telehandlers and skid steers. The tree shear attachment / tree lopper is becoming increasingly used in many forestry applications due to the time and money saving advantages it offers. It is a single service attachment that works off your existing double acting hammer circuit. With one powerful hydraulic ram, this excavator tree shear is forgiving to imprecise alignment of the blade by the operator and consequently facilitates faster cutting.
Applications
Tree shears are landscaping products mounted on excavators, skid steers to cut tree branches. It can quickly cut trees, branches, bamboo, etc.
Our Advantages
MONDE excavator tree shear is one of the easiest tree shears to use on the market, with quick and easy alignment and a simple grab-to-cut action, the cutting cycle is rapid. Fitted with a bolt-on Hardox 500 blade for an extra sharp cut with extended durability, this tree shear can cut through hardwoods of up to 200-350 mm in one motion..
Packaging & Delivery
1.We pack the products by simple pallet or case which is seaworthy.
2.Fast delivery time:5-7 days for small quantity,and 20-30 days for container quantity.
3.We have a team specialized in packing and loading container, they have rich experience,and can load the max quantity products,which can help customer save the ocean freight.
