Quick Details
-
Brand Name:
-
Chinasky, OEM
-
Model Number:
-
PSE1290WW-10G
-
Place of Origin:
-
Zhejiang, China
-
PoE Standard:
-
IEEE802.3af/at
-
Applications:
-
Support PoE IP camera, PoE WIFI AP, and PoE IP Phone
-
Product Description:
-
4 8 16 24 48 Port CCTV Network Ethernet PoE Switch 48V
-
PoE Ports:
-
4, 8, 16, 24, 32, 48 Ports Support PoE
-
Bandwidth:
-
1.6G, 2.2G, 2G,10G, 12G, 12.8G, 16G, 17.8G, 20G, 56G
-
Protections:
-
short-circuit protection, Over-voltage and under-voltage protection
-
Warranty:
-
3 years
-
Certification:
-
CE, RoHS, FCC, IEC60950-1
-
Waterproof grade:
-
IP67
-
Working Temperature:
-
-40°C~70°C
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
1Gbps
-
Brand Name:
-
Chinasky, OEM
-
Model Number:
-
PSE1290WW-10G
-
Place of Origin:
-
Zhejiang, China
-
PoE Standard:
-
IEEE802.3af/at
-
Applications:
-
Support PoE IP camera, PoE WIFI AP, and PoE IP Phone
-
Product Description:
-
4 8 16 24 48 Port CCTV Network Ethernet PoE Switch 48V
-
PoE Ports:
-
4, 8, 16, 24, 32, 48 Ports Support PoE
-
Bandwidth:
-
1.6G, 2.2G, 2G,10G, 12G, 12.8G, 16G, 17.8G, 20G, 56G
-
Protections:
-
short-circuit protection, Over-voltage and under-voltage protection
-
Warranty:
-
3 years
-
Certification:
-
CE, RoHS, FCC, IEC60950-1
-
Waterproof grade:
-
IP67
-
Working Temperature:
-
-40°C~70°C
CCTV 90W IP67 802.3af/at/PoE++/BT 10G Waterproof Industrial Extender PoE Injector(PSE1290WW-10G)
CCTV 90W IP67 802.3af/at/PoE++/BT 10G Waterproof Industrial Extender PoE Injector(PSE1290WW-10G)
|
Model |
PSE 12 90W-10G |
|
Product name |
90W 802.3af/at/PoE++/BT 10G Waterproof Industrial PoE Injector |
|
material |
Aluminum die-casting body Nylon waterproof joint |
|
Waterproof grade |
I P67 |
|
Wire diameter |
Support network cables with a Φ of 4-8mm |
|
Fixed Port |
1*10/100/1000/ 2500M/5G/10G -TX in 1*10/100/1000/ 2500M/5G/10G -TX out |
|
P ower in |
DC supports input anti reverse function 2P * 3.81 terminal input |
|
Voltage input range |
D C12-57V MAX 140W |
|
Conversion efficiency |
9 0-95% |
|
Voltage out range |
D C48-52V |
|
P o E OUT |
Supports IEEE802.3af/at/bt, max 90W PoE out |
|
P oE OUT Pin |
12+ 45+ 36- 78- |
|
P OE out Transmission Distance |
10BASE-T : Cat3,4,5 UTP(≤250 meter) 100BASE-TX : Cat5 or later UTP(150 meter) 1000BASE-TX : Cat6 or later UTP(100 meter) 2500BASE-TX : Cat6 or later UTP(100 meter) 5G-TX : Cat6 or later UTP(90 meter) 10G-TX : Cat6 or later UTP(30 meter) |
|
LED Indicator |
Power : Power in LED , Boost voltage normal LED P OE out: on of af/at LED , o n off bt LED |
|
Operating Temperature/Humidity |
-40~ +80°C ; 5% ~ 90% RH Non coagulation |
|
Storage Temperature/Humidity |
-40~ +90°C ; 5% ~ 95% RH Non coagulation |
|
Product /Packing size( L*W*H ) |
150*77*43mm 160*85*47mm |
|
N.W/G.W( kg ) |
0.27kg/0.31kg |
|
Lightning Protection level |
6KV 8/20us; |
|
Installation |
Desktop , wall installation |
|
Certificate |
CE-EMC EN55032 ; CE-LVD EN62368 ; FCC Part 15 Class B; RoHS ; |
