Quick Details
-
Model Number:
-
BKL Series
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
AKUSENSE
-
Theory:
-
Magnetic field induction
-
Output:
-
Switching Transducer
-
Brand:
-
Akusense Infrared Safety Light Curtain
-
Voltage - Supply:
-
24V DC
-
Output Type:
-
Switch output
-
Current - Supply:
-
<200mA
-
Features:
-
High Speed Response
-
Current:
-
<200mA
-
Measuring Range:
-
0.1-6M
-
Sensing Range:
-
0.1-6M
-
Sensing Distance:
-
0.1-6M, 0.1-6M
-
Protection Area:
-
120 - 3000mm
-
Beam pitch:
-
10/20/40mm
-
Response time:
-
≤ 10ms
-
Current Consumption:
-
200mA
-
Operating voltage:
-
12~24VDC ±10%
-
Sychronization type:
-
Line Sychronization
-
Output type:
-
NPN/PNP
-
Material:
-
Aluminium alloy
-
Connector:
-
M12
Quick Details
-
Usage:
-
Safety Light Curtains
-
Mounting Type:
-
screw mounting
-
Description:
-
area protective sensor
-
Model Number:
-
BKL Series
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
AKUSENSE
-
Theory:
-
Magnetic field induction
-
Output:
-
Switching Transducer
-
Brand:
-
Akusense Infrared Safety Light Curtain
-
Voltage - Supply:
-
24V DC
-
Output Type:
-
Switch output
-
Current - Supply:
-
<200mA
-
Features:
-
High Speed Response
-
Current:
-
<200mA
-
Measuring Range:
-
0.1-6M
-
Sensing Range:
-
0.1-6M
-
Sensing Distance:
-
0.1-6M, 0.1-6M
-
Protection Area:
-
120 - 3000mm
-
Beam pitch:
-
10/20/40mm
-
Response time:
-
≤ 10ms
-
Current Consumption:
-
200mA
-
Operating voltage:
-
12~24VDC ±10%
-
Sychronization type:
-
Line Sychronization
-
Output type:
-
NPN/PNP
-
Material:
-
Aluminium alloy
-
Connector:
-
M12
Product Description
Protection Range
0.1-6M protection range, huge safety area for dangerous operation.
Response Time
10ms high speed response time, quickly give signal when detect human.
Price
Competitive price but reliable performance.
Specification
|
Sectional area
|
30*30mm
|
|
|
|
|||
|
NO.of beams
|
4-256
|
|
|
|
|||
|
Protection height
|
0.1-6M
|
|
|
|
|||
|
Beam pitch
|
10/20/40mm
|
|
|
|
|||
|
Min. sized detectable objects
|
＞φ14/25/φ45mm, opaque
|
|
|
|
|||
|
Supply voltage
|
24V DC±10%
|
|
|
|
|||
|
Current consumption
|
＜200mA
|
|
|
|
|||
|
Power consumption
|
3~8W
|
|
|
|
|||
|
Output type
|
NPN/PNP
|
|
|
|
|||
|
Synchronization type
|
line synchronization
|
|
|
|
|||
|
Response time
|
≤10ms
|
|
|
|
|||
