Quick Details
-
Circulation Type:
-
Direct / Open Loop (Active)
-
Capacity:
-
100, 100-320
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Dr.Sunshine
-
Model Number:
-
YGBS-DB-58/1800-10-32
-
Vacuum tube diameter:
-
58mm
-
Outer tank:
-
Colour Galvanized Steel Plate
-
Inner tank:
-
SUS 304-2B Stainless Steel/0.4mm
-
Insulation:
-
High Density Polyurethane Foaming
Quick Details
-
Warranty:
-
3 years
-
Application:
-
Hotel, Commercial, Household
-
Type:
-
Evacuated Tube
-
Circulation Type:
-
Direct / Open Loop (Active)
-
Capacity:
-
100, 100-320
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Dr.Sunshine
-
Model Number:
-
YGBS-DB-58/1800-10-32
-
Vacuum tube diameter:
-
58mm
-
Outer tank:
-
Colour Galvanized Steel Plate
-
Inner tank:
-
SUS 304-2B Stainless Steel/0.4mm
-
Insulation:
-
High Density Polyurethane Foaming
Description
1..Inner tank 0.4mm SUS304 stainless steel.
2.Insulation layer thickness for the temperature difference in various regions to provide 50mm/60mm/70mm optional.
3.Outer tank is 0.4mm color steel.
4.Frame is 1.5 mm zinc-coated.
5.Use super heat glass pipe.
1. Use super heat glass pipe, has advantage of high temperature, fast heat transfer,anti-leaking.
2.Fast starting up, fast reaction.
3.Sealed inner tube, can endure high pressure.
4.No water inner the tube, anti-chilliness, no dirty, anti-leaking.
5.Use super heat glass pipe has the function of diode thermal single transmit, avoiding thermal dissipate.
|
Model
|
Product Size(mm)
|
Lighting(m
2
)
|
Capacity(L)
|
GW(kg)
|
Qty*per 20' Container
|
Qty*per 40' Container
|
|
YGBS-DB-75-58/1800-10
|
1990*1740*1820
|
1.47
|
100
|
66
|
68
|
156
|
|
YGBS-DB-75-58/1800-12
|
1150*1740*1820
|
1.77
|
120
|
72
|
60
|
145
|
|
YGBS-DB-75-58/1800-15
|
1390*1740*1820
|
2.45
|
150
|
82
|
51
|
117
|
|
YGBS-DB-75-58/1800-18
|
1630*1740*1820
|
2.66
|
180
|
88
|
44
|
102
|
|
YGBS-DB-75-58/1800-20
|
1790*1740*1820
|
2.99
|
200
|
94
|
40
|
92
|
|
YGBS-DB-75-58/1800-24
|
2110*1740*1820
|
3.56
|
240
|
114
|
34
|
78
|
|
YGBS-DB-75-58/1800-30
|
2590*1740*1820
|
4.42
|
300
|
134
|
27
|
62
|
|
YGBS-DB-75-58/1800-32
|
2750*1740*1820
|
4.73
|
320
|
140
|
25
|
58
|
