Quick Details
-
Voltage:
-
AC 220 to 240V
-
Make:
-
Roland
-
Dimensions(L*W*H):
-
2575mm*795mm*1270mm
-
Weight:
-
140 KG
-
Print Dimension:
-
1615mm
-
Ink Type:
-
roland eco-sol max2 ink
-
Print head:
-
used DX7 print head
-
Resolution:
-
1440dpi
-
Color:
-
CMYK
-
Medium thickness:
-
Max 1.0mm
-
Medium weight:
-
Max 40kg
-
Roll outer diameter:
-
Max 210mm
-
Output(sqm/h):
-
12
-
Ink cartridge:
-
440cc
Quick Details
-
Year:
-
2016
-
Place of Origin:
-
Japan
-
Brand Name:
-
Roland
-
Voltage:
-
AC 220 to 240V
-
Make:
-
Roland
-
Dimensions(L*W*H):
-
2575mm*795mm*1270mm
-
Weight:
-
140 KG
-
Print Dimension:
-
1615mm
-
Ink Type:
-
roland eco-sol max2 ink
-
Print head:
-
used DX7 print head
-
Resolution:
-
1440dpi
-
Color:
-
CMYK
-
Medium thickness:
-
Max 1.0mm
-
Medium weight:
-
Max 40kg
-
Roll outer diameter:
-
Max 210mm
-
Output(sqm/h):
-
12
-
Ink cartridge:
-
440cc
Scope of application
Roland photocopier RF640A/RF640 This device can be used for advertising signage, photo-painting, outdoor advertising, printing, home decoration, industrial design, industrial processing and manufacturing, studio images, digital printing and dyeing, art reproduction, crafts processing, clothing printing, sports equipment printing, car decoration, packaging printing, oil painting reproduction, art glass, art mobile door and other industries. For more information on the application of this product and Roland photocopying machine RF640A/RF640 equipment, please consult customer service.
Product Description
Detail
Specification
|
Automatic Grade
|
Automatic
|
|
Color & Page
|
Multi color
|
|
Plate Type
|
Inkjet Printers
|
|
Voltage
|
AC 220 to 240V
|
|
Warranty
|
3 months
|
|
Printer Model
|
RF640
|
|
Model
|
|
RF-640A/RF640
|
||
|
How to print
|
|
Piezoelectric inkjet printing
|
||
|
medium
|
width
|
Reel media: 259 to 1625 mm
|
||
|
|
thickness
|
Reel media: up to 1.0 mm including liner
|
||
|
|
weight
|
Reel media: up to 40 kg
|
||
|
|
The outer diameter of the volume
|
Up to 210 mm
|
||
|
|
Kernel diameter x1
|
76.2mm / 50.8mm with optional rim
|
||
|
Paper collection system
|
|
Outer diameter Up to 210 mm / weight up to 40 kg
|
||
|
Print width x2
|
|
Up to 1615 mm
|
||
|
Maximum print speed
|
|
56.8 sq.mph (360x360 dpi)
|
||
|
cartridge
|
type
|
Roland FPG water-type ink 220cc cartridge
|
||
|
|
color
|
4 colors (green, magenta, yellow, black)
|
||
|
Print resolution
|
|
Up to 1440 dpi
|
||
|
Paper-walking accuracy x3
|
|
The paper distance error is less than 0.3% ± or 0.3mm ±, whichever is greater.
|
||
|
Media heating system x4
|
|
Set range of preset temperature: print heating 30 to 45 degrees C / after heating: 30 to 50 degrees C
|
||
|
interface
|
|
Ethernet (10BASE-T/100BASE-TX, adaptive)
|
||
|
Power-saving function
|
|
Auto-sleep function
|
||
|
power supply
|
Voltage and frequency
|
AC 100 to 120 V ± 10%, 8.1A, 50/60 Hz 或AC 220 to 240 V ± 10%,4.1A, 50/60 Hz
|
||
|
Power consumption (excluding paper collection system)
|
Runtime
|
About 1070 W
|
||
|
|
Sleep mode
|
About 14.5W
|
||
|
Size (when scaffolding is included)
|
|
2575[W]x795[D]x1270[H] mm
|
||
|
Weight (when scaffolding is included)
|
|
140kg
|
||
|
environment
|
Runtime
|
Temperature: 15 to 32 degrees C (recommended above 20 degrees C) / Humidity: 35 to 80% RH (no condensation)
|
||
|
|
Not running
|
Temperature: 5 to 40 degrees C Humidity: 20 to 80% RH (no condensation)
|
||
|
Contains attachments
|
|
Brackets, power cords, media clips, media flanges, paper cutter replacement tools, user manuals, etc.
|
||
|
1、The printer's media stand only supports 3-inch core diameter media. To use 2 inches of media, purchase an additional media
flange option. 2、The length of printing or cutting is limited by the program. 3、 Using Roland-specified media, print travel of 1 m, temperature: 25 degrees C (77 degrees F), humidity: 50% RH, when using printer heater or dryer, is not guaranteed. 4、 Warm-up is required when the power supply is switched on. It may take 5 to 20 minutes to warm up, depending on the working environment. Due to the influence of ambient temperature and media width, the preset temperature may not be reached. |
|
|
||
Better value for money, more efficient production, better reliability.
Roland VersaEXPRESS ™ RF-640A is the perfect solution for digital printing: higher productivity, superior print quality, unparalleled stability, ease of operation. The RF-640A is known for its ability to print high-quality images and works quickly and efficiently, while keeping operating costs low. In short, its efficient production, in the vast number of customers recognized at
the same time, for users to obtain higher profits.
the same time, for users to obtain higher profits.
High efficiency and excellent print quality
The RF-640A's efficient printing is ideal for continuous work environments. While printing high-precision images, high-quality output is guaranteed. The device is equipped with a stand for adjustable media, making it easy to support both narrow and wide volumes. The RF-640A offers maximum wide-format printing speeds of 56.8m2/h through improvements to high precision print control
technology. The new media automatic rewinding device, with high steel shaft and stable fixed bracket, supports high-volume printing and improves the run-off phenomenon when printing media. In addition, VersaEXPRESS ™ RF-640A-compatible RIP software on the market, resulting in smoother workflows and increased production.
technology. The new media automatic rewinding device, with high steel shaft and stable fixed bracket, supports high-volume printing and improves the run-off phenomenon when printing media. In addition, VersaEXPRESS ™ RF-640A-compatible RIP software on the market, resulting in smoother workflows and increased production.
Perfect print quality
The RF-640A is equipped with the latest printhead technology, and even at higher speeds, the RF-640A prints beautiful and full colors. The print head is equipped with variable droplets to ensure stunning images on a wide range of media at high speeds.
:: Roland Intelligent Pass Control ™ (Roland Intelligent Control Printing System).
:: Roland Intelligent Pass Control ™ (Roland Intelligent Control Printing System).
Smart choice, easy to use
The RF-640A is not only available to professionals. In fact, because of the innovative features and technical advantages of this camera, it is extremely simple to operate. With the Roland Printer Assistant iPad APP software, you can remotely control production, print testing and even ink cleaning with your iPad tablet. The easy-to-operate front load cartridge system, the media loading lever mounted on the front and rear of the printer, and a stand that supports up to 40kg of reel media make the device easier to use.
Save money anytime, anywhere
The RF-640A's special design makes it very low operating cost and easy to maintain. Accurate inkjet technology and optimized ICC curves, combined with Roland FPG ink, reduce ink usage. Automatic nozzle maintenance systems extend the life of the nozzle, all of which allow the RF-640A to remain energy efficient and environmentally friendly in production and standby mode.
