Quick Details
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Kangheng
-
Model Number:
-
DIN 1.6582 / AISI 4340, GB 40CrNiMoA /DIN 1.6582 /AISI 4340
-
Material:
-
1.6582 Hot work steel
-
Surface treatment:
-
Black/Grinded/Machined/Turned
-
Certification:
-
ISO9001
-
Production route:
-
EF/EAF+LF+VD/ESR
-
UT test standard:
-
SEP1921-84 class3 C/c to D/d
-
Quality inspection:
-
UT, Chemical test, Microstructure, Physical properties etc.
Quick Details
-
Steel Grade:
-
4140 steel
-
Tolerance:
-
±1%
-
Grade:
-
Alloy steel, SAE 4340 carbon steel plate price
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Kangheng
-
Model Number:
-
DIN 1.6582 / AISI 4340, GB 40CrNiMoA /DIN 1.6582 /AISI 4340
-
Material:
-
1.6582 Hot work steel
-
Surface treatment:
-
Black/Grinded/Machined/Turned
-
Certification:
-
ISO9001
-
Production route:
-
EF/EAF+LF+VD/ESR
-
UT test standard:
-
SEP1921-84 class3 C/c to D/d
-
Quality inspection:
-
UT, Chemical test, Microstructure, Physical properties etc.
SAE 4340 carbon steel plate price
Related Products
Product Description
| Steel Type | |||||
| GB | AISI | DIN | JIS | BOHLER | Ss14 |
| 40CrNiMoA | 4340 | 1.6582 | SACM639 | / | / |
| Chemical Composition | ||||||||
| C | Si | Mn | P | S | Cr | Mo | V | Ni |
| 0.38-0.44 | 0.17-0.35 | 0.60-0.80 | ≤0.025 | ≤0.025 | 0.70-0.90 | 0.20-0.30 | / | 1.25-1.65 |
| Size of 1.6582(Can be Customised) | |||
| Round Bar | Diameter(mm) | Hot Forged: φ50-500 | Length(mm):2500-5000 |
| Hot Rolled:≤50mm | |||
| Steel Plate | Thickness(mm) | Hot Forged:≥20mm | Width(mm):20-810 mm |
| Hot Rolled:≤20mm | |||
| Tolerance | ||||
| Round Bar | Black Surface | Peeled Surface | Turned Surface | |
| -0/+5mm | -0/+3mm | -0/+2mm | ||
| Steel Plate | Black Surface | Machined Surface | ||
|
Thickness:
-0/+5mm
|
Width:-0/+10mm | Thickness:-0/+3mm | Width:-0/+5mm | |
| Characteristics: | |||
| 1.Low alloy steel containing nickle,chromium and molybdenum; | |||
| 2.It is known for its toughness and capability of developing high strength in the heat treated condition. | |||
| Applications: | |||
| Typical applications are for structural use ,such as aircraft landing gear ,power transmission geras and shafts | |||
| and other structural parts. |
| Noted | |||
|
(1) Payment : 1.By confirmed, 100% valum irrevocable, letter of credit without recourse, Allowing partial shipment and transhipment, payable at sight presentation of shipping. |
|||
| 2.By T/T payment: 30% payment in deposited, 70% payment before shipment. | |||
| (2) Delivery Time : 45 days after received the buyer's L/C or T/T deposite payment. | |||
| (3) Delivery Port : Wuhan/Shanghai/Tianjin | |||
| (4) Process: Electric furnace melted, forged and annealed, round bar turned, flat bar machined. | |||
| (5) Hardness: Annealed HB235 MAX. | |||
| (6) UT Test: SEP 1921/84/2 C/c class. | |||
| (7) Allowance on quantity/weight: -/+ 10% per item. | |||
| (8) Package: Seaworthy Packing. |
