Quick Details
-
Weight:
-
3500KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support
-
Type:
-
Packing Machine
-
Function:
-
Automatic Book Cover Making
-
Usage:
-
Automatic Book Cover Making
-
Color:
-
White & Gray
-
Machine name:
-
Automatic Book Cover Making Machine
-
Certification:
-
CE
Quick Details
-
Brand Name:
-
HORDA
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
8500X2600X1500mm
-
Weight:
-
3500KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support
-
Type:
-
Packing Machine
-
Function:
-
Automatic Book Cover Making
-
Usage:
-
Automatic Book Cover Making
-
Color:
-
White & Gray
-
Machine name:
-
Automatic Book Cover Making Machine
-
Certification:
-
CE
Products Description
ZFM-900A Automatic hard cover case making paper case making Book Cover Making Machine
ZFM-700/900/1000/1350 Series Automatic Case Making Machine uses servo driving, photoelectric detecting, servo positioning and other new technologies as well. They can finish teh processes of paper feeding, gluing, board feeding, positioning and four-side folding automatically with high accuracy, fast speed and high quality . It is teh effective solution for customers of printing and packaqing industry with high-volume production in producing teh package for wines, cigarettes, moon cakes, tea, mobile phones, underwear, handicrafts, and cosmetics etc, making file folders, calendars, and other hardcover books as well.
Main Specification
|
Model
|
ZFM-700A
|
ZFM-900A
|
ZFM-1000A
|
ZFM-1350A
|
|
Maximum Size
|
450mm×720mm
|
450mm×950mm
|
600mm×1050mm
|
600mm×1350mm
|
|
Minimum Size
|
90mm×180mm
|
90mm×180mm
|
140mm×240mm
|
140mm×240mm
|
|
Board Thickness
|
1.0-3.0mm
|
1.0-3.0mm
|
1.0-3.0mm
|
1.0-3.0mm
|
|
Paper Weight
|
105-210g
|
105-210g
|
105-210g
|
105-210g
|
|
Maximum Speed
|
20-30 picecs/min
|
20-30 picecs/min
|
15-25 picecs/min
|
10-20 picecs/min
|
|
Power Supply
|
16KW/380V
|
17.5KW/380V
|
18KW/380V
|
19KW/380V
|
|
Dimension(L×W×H)
|
8500× 2600×1500mm
|
9750× 2600×1500mm
|
10440×3000×1500mm
|
11500×3000×1500mm
|
|
Machine Weight
|
3500kg
|
4000kg
|
5000kg
|
6000kg
|
|
Position Accuracy
|
±0.25mm
|
±0.25mm
|
±0.25mm
|
±0.25mm
|
|
Boards amount
|
1-6pieces
|
1-6pieces
|
1-6pieces
|
1-5pieces
|
|
Min spine width
|
8mm
|
8mm
|
8mm
|
8mm
|
|
Min side-board width
|
25mm
|
25mm
|
25mm
|
25mm
|
Product video
In the past ten years, we've been concentrating on the research and development of paper packing equipment. We have founded four series for dozens of hit products, including automatic case making machine, Wine&cigarette case production line, mobile phone case production line, collapsible box production line.
