Quick Details
-
Voltage:
-
380V/220V
-
Power:
-
40~60KW
-
Dimension(L*W*H):
-
6*4*3 Meters
-
Weight (KG):
-
6500
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Application:
-
Industries
-
After Warranty Service:
-
Video technical support
Quick Details
-
Machine Type:
-
PVD vacuum coating machine., Painting Equipment, Plc Controller Programmable Logic Controller, Pre-treatment Equipment, Conveying Equipment, Curing oven, Coating Equipment, Anodized Equipment, Other
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
junying
-
Voltage:
-
380V/220V
-
Power:
-
40~60KW
-
Dimension(L*W*H):
-
6*4*3 Meters
-
Weight (KG):
-
6500
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Application:
-
Industries
-
After Warranty Service:
-
Video technical support
PVD vacuum coating equipment specification:
Limit vacuum:8.0×10-4 Pa.
* Suction time:Atmosphere to 6.0×10-2 Pa ≤ 6min.
* Booster rate (holding): 0.67 Pa/ hr.
* Turn frame work movement way :
The disc common rotation movement,6 axis (can be designed according to customer requirements) . The revolution speed 0 ~ 6 RPM ,Inverter control ac three-phase motor.
* Host total power
Total power about 70 KVA (three-phase four-wire + ground), auxiliary equipment users should bring along their own. (Mexico with 60 HZ 180 V since the transformer)
3 . Users should bring along their own
3 -1The cold water supply 15-25, flow 20 T/H, pressure 0.15 ~ 0.25 MPa.
3 -2 Compressed air, pressure 5 ~ 6 kg.
4 . Host weight The weight of about 5500kg.
5. Type application:
This coating machine applicable to the plating system decorative membrane, mainly with the preparation of metal film,
that is, in the vacuum chamber using resistance heating, will close to the wire in resistance wire molten metal molecular
deposition in the vaporization of substrate, and obtain smooth reflectivity membrane layer to decorate beautification
object surface purpose. Suitable for and ABS, PS, PC, PVC, TPU, jewelry, hardware, mobile phone, toys,
reflective lass, cosmetics, etc.
|
Serial number |
Name |
Specifications |
qty |
unit |
|||
|
1 |
Pump system |
H-150 mechanical pump (zhejiang) |
1 |
set |
|||
|
2 X-15 maintain pump (outdoor) |
1 |
set |
|||||
|
ZJY-600 roots pump (Shanghai) |
1 |
set |
|||||
|
KT-800 diffusion pump |
1 |
set |
|||||
|
2 |
Vacuum Chamber |
1 4 00 mm * 1 6 00 mm |
1500mm* 1800mm |
1600mm* 1800mm |
1800mm* 2000mm |
1 |
set |
|
using Q235 carton steel materials , turn frame 2 sets, match a watch window |
|||||||
|
3 |
Valve line |
Pipeline as stainless steel materials, vacuum valve for carbon steel. |
1 |
set |
|||
|
4 |
Workpiece rotate system
|
1, steamed plating rotating way: common rotation type 2 groups. 2, common rotation type of effective size: Phi 600 x 1700 mm (diameter × length) 6 axis 3, and turn to drive the motor power: 0.75 KW one. (variable frequency speed regulation) |
1 |
set |
|||
|
5 |
Measure m ent control instrument |
HY-9940-B composite vacuum measuring instrument |
1 |
set |
|||
|
7 |
Electric Control system |
Germany Siemens PLC + kunlun the state 10.4 "hand touch screen automatic control operation. |
1 |
set |
|||
|
8 |
power |
33 KW /12V Evaporation transformer 33 K W / 12 V |
1 |
set |
|||
|
9 |
Protection function |
Equiped hydraulic pressure loss, gas pressure loss, automatic alarm and interlock function. |
1 |
set |
|||
|
10 |
S pare parts |
The instruction for use, plane installation drawing, circuit connecting diagram, Spare parts list, technical parameters acceptance list |
1 |
set |
|||
1. Professional sales person and technical team to lead you to invest the project with best budget.Turn-key project offering.
2. Quality control,high technology productivity to make sure the good quality machine production.
3.1 year warranty was provided since the date of delivery. In 1 year's warranty,For small problems about the machine,our profesional after-sales team will help to solve on line.For big problem,we will dispatch the engineer to your factory to solve problem.Large experienced engineer team is ready to serve all of you in the whole of the world.
We can design the dimension of the vacuum chamber according to your requirements. We can also design and configure the vacuum unit and electric controlling system according to your requirement. .
