Edgelight high quality linear AD-EL-2401200 white swith power supply DC24V 120W slim led driver

Edgelight high quality linear AD-EL-2401200 white swith power supply DC24V 120W slim led driver

Printing can be customized.

This product is a 24V120W, 5A a long type series of non dimming built-in PFC function of single chanel output LED driver power supply, protection grade is IP20 indoor installation; with short circuit, over voltage, temperature protection function.

Features

• Rated power :120W
• The efficiency is as high as 100%
• Input voltage: 100-240V AC
• The power factor: built-in PFC function, PF>0.9 when full load
• The output current: 5A
• Protection: short circuit/ overload/ over temperature
• Meet the requirements of EMC (EN55015 Class B)
• 100% full load burn-in test
• High reliability
• When the rated input voltage, full load, ambient temperature is 25 degrees Celsius, the average power supply no failure time at least 50000 hours

Environmental requirements

• Working temperature:-25-50 degrees
• Storage temperature (with a shell): -25-55 degrees
• Working humidity: 20%-95%, RH no condensation

Application:

Maybe needed accessories:

Note

1.Avoid  use in outdoor or harsh environment, to prevent the power exposure or damp. At the same time, ensure that the power supply has a good heat radition environment, ensure safety.

2.When you don't use the power adapter, please unplug the power, when the power supply is working, please don't touch with hand directly.

3.Please don't short circuit when output, if no output, please power off one minute and then power on.

4.Before the power is used, please confirm whether the power supply is connected properly to prevent power line inversely connection.

5.Please put the power in the place where children can not contact.

6.Power supply plugs are different, please pay more attention if is suitable for the product when choice.
