Quick Details
-
Material:
-
Metal
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
JINGYE
-
Model Number:
-
JINGYEDC05
-
Customed Size:
-
Available
-
MOQ:
-
12 sets; Office Filing Cabinet
-
Certificate:
-
ISO9000 & ISO14001; book store shelves
-
Style:
-
Office Filing Cabinet; book store shelves
-
Color:
-
Black, Grey OR Optional; book store shelves
-
Type of company:
-
Manufacturer; collapsible metal shelves
-
Finishing:
-
Epoxy powder coated, antirust; collapsible metal shelves
-
Warranty:
-
3 years on normal use; book store shelves
-
Structure:
-
Knock down; collapsible metal shelves
-
After-Sales Service:
-
≥3 Years
Quick Details
-
Feature:
-
Adjustable (height)
-
Application:
-
Office Building, Hospital, School
-
Design Style:
-
Modern
-
Material:
-
Metal
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
JINGYE
-
Model Number:
-
JINGYEDC05
-
Customed Size:
-
Available
-
MOQ:
-
12 sets; Office Filing Cabinet
-
Certificate:
-
ISO9000 & ISO14001; book store shelves
-
Style:
-
Office Filing Cabinet; book store shelves
-
Color:
-
Black, Grey OR Optional; book store shelves
-
Type of company:
-
Manufacturer; collapsible metal shelves
-
Finishing:
-
Epoxy powder coated, antirust; collapsible metal shelves
-
Warranty:
-
3 years on normal use; book store shelves
-
Structure:
-
Knock down; collapsible metal shelves
-
After-Sales Service:
-
≥3 Years
|
Shelf body |
Stand Column |
Cold-roll steel |
1.5mm |
GB708 |
|
Partition Whole body partition partition flange 25mm (reinforcing rib under the partition) |
Cold-roll steel |
1.0mm |
GB708 |
|
|
Side plate |
Cold-roll steel |
1.0mm |
GB708 |
|
|
Upper cover plate (whole body side plate dimension 300X100mm) |
Cold-roll steel |
1.0mm |
GB708 |
|
|
Panel |
Cold-roll steel |
1.0mm |
GB708 |
|
|
chassis |
Main beam and whole frame board (every wheelo frame board have six : 55mm beam bush hole. every hole have sealing |
Hot rolled steel plate |
3.0mm |
GB710 |
|
pathway |
Rail |
High quality steel plate |
Solid square tube |
GB710 |
|
Rail box |
High quality steel plate |
26X95mm Thickness 3.0 |
GB710 |
|
|
Pathway |
High quality steel plate |
50X185 Thickness 3.0 |
GB710 |
|
|
Transmission part |
Handle crank |
ZG45 |
Bothway overload clutch double axis transmission |
GB1285 |
|
Transmission shaft |
Solid core 45 steel |
Φ 20 |
GB699 |
|
|
Linkage rail |
Seamless steel tube |
Φ 20X2.5 |
GB699 |
|
|
Bearing |
Precision bearing |
HR6204 |
GB/T 307.3-2005 |
|
|
Chain wheel |
ZG45 |
GB1135 |
||
|
Chain |
FR420 |
Φ 8.5, pitch12.7 breaking force 1800kg |
GB1244 |
|
|
Idler wheel |
HT20-40 |
Cast iron |
Gb11351 |
|
|
Sealing rubber strip |
Magnetic fluid sealant |
|||
|
Dust shield |
Cold-roll steel |
1.0 |
Gb710 |
|
|
Barb |
Hot rolled steel plate |
3.0mm |
Gb711 |
1. who are we?
We are based in Ningbo, China, start from 1995.
2. how can we guarantee quality?
Always a pre-production sample or effect drawing provide before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Banks safe deposit box, vault room, vault door, dense cabinet, arvhive shelf and so on
4. why should you buy from us not from other suppliers?
Your "Safe products" for All your needs!
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,Express Delivery;
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,PayPal,Cash;
Language Spoken:English,Chinese
