Quick Details
-
Dimension(L*W*H):
-
3300(mm)x1800(mm)x2400(mm)
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Certification:
-
ce, ce, Other
-
Design:
-
Hook,spinner
-
Chamber size:
-
Dia.800x1500
-
shot blasting machine:
-
hook
-
type:
-
shot blasting machine
-
Production Capacity:
-
60-520 T/h
-
Condition:
-
New
-
Voltage:
-
220/280/350/380v
-
Weight:
-
3500kgs
-
Warranty:
-
1 Year
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
C&J
-
Power:
-
11-15KW
-
Dimension(L*W*H):
-
3300(mm)x1800(mm)x2400(mm)
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Certification:
-
ce, ce, Other
-
Design:
-
Hook,spinner
-
Chamber size:
-
Dia.800x1500
-
shot blasting machine:
-
hook
-
type:
-
shot blasting machine
-
Production Capacity:
-
60-520 T/h
-
Condition:
-
New
-
Voltage:
-
220/280/350/380v
-
Weight:
-
3500kgs
-
Warranty:
-
1 Year
This model is suitable for cleaning or reinforcing various medium and large batch forged piece, casting and sheet metal parts but also more suitable for frosting surface after rust removal and increasing adhesive force of spraying. There are models of Q375 single-hook shot blasting machine, Q376 double-hook shot blasting machine and Q378 double-hook shot blasting machine etc. Characteristics:
1.
This machine adopts no-pit structure which is easy to be mounted and thus reduce investment cost.
2.
Compact structure, high efficiency, good cleaning quality, reliable and safe operation, steady running.
3.
The cleaning chamber is wear-resisting and impact resistant with good intensity by adopting High Chromium Manganese plate.
4.
Double-hook structure, which can work independently, neither influencing the other, thus improve production efficiency. The hook adopts planet principle with simultaneous rotation and revolution. The processed work piece doesnt have male and female face.
5.
Two-stage dust removal (cyclone dust removal and bag filter), great air volume, the dust is completely filtered, and the air discharge is in compliance with environment protection standard.
6.
Precise assembly, high-quality bearing, and low noise of motor running.
Packing: One set bulk packing in 1x20'FCL.
Delivery time: 45-50days.
Payment: T/T35%deposit, the balance is paid before shipment after receiving our correct machine pictures and packing photos.
Attached our actual production shot blasting machine for you reference .
Technical data as below:
|
No.
|
descprtion
|
unit
|
Q378C
|
|
1
|
Machine size
|
mm
|
4844x3850x5156
|
|
2
|
Single hook limit weight
|
kg
|
1000
|
|
3
|
Shot blasting capacibility
|
kg/min
|
2x250
|
|
4
|
Separating capacilibity
|
T/h
|
30
|
|
5
|
Bucket elevating capacilibity
|
T/h
|
30
|
|
6
|
Size of the workpiece
|
mm
|
Dia.800x1500
|
|
7
|
Ventilation volume
|
m3/h
|
8300
|
|
8
|
Total power
|
kw
|
37.04
|
