Quick Details
-
Warranty:
-
1 year
-
Brand Name:
-
Milestone
-
Model Number:
-
ZD120-50
-
Place of Origin:
-
Hebei, China
-
Horsepower:
-
120hp to 293hp
-
Cable Length:
-
None
-
Outlet Size:
-
125mm
-
Power:
-
55kw-220kw
-
motor:
-
as customer request
-
Total impeller stage:
-
9 stage
-
Head(m):
-
100-450
-
Speed(rpm):
-
2950
-
Inlet(mm) /Outlet(mm):
-
125
-
NPSHr(m):
-
4.2
-
Efficiency(%):
-
73
-
Pump casing:
-
cast iron
-
Shaft seal:
-
Packing seal
-
Certification:
-
ce
Quick Details
-
Application:
-
Industrial Utilities, Irrigation and Agriculture, Water Treatment Solutions
-
Pressure:
-
High Pressure
-
Voltage:
-
380v/400V/440V
-
Warranty:
-
1 year
-
Brand Name:
-
Milestone
-
Model Number:
-
ZD120-50
-
Place of Origin:
-
Hebei, China
-
Horsepower:
-
120hp to 293hp
-
Cable Length:
-
None
-
Outlet Size:
-
125mm
-
Power:
-
55kw-220kw
-
motor:
-
as customer request
-
Total impeller stage:
-
9 stage
-
Head(m):
-
100-450
-
Speed(rpm):
-
2950
-
Inlet(mm) /Outlet(mm):
-
125
-
NPSHr(m):
-
4.2
-
Efficiency(%):
-
73
-
Pump casing:
-
cast iron
-
Shaft seal:
-
Packing seal
-
Certification:
-
ce
video description
Products Description
Based Upon the standard of JB/1o51.D series multi-stage centrfugal pumps are a new generation of high-efficiency and energy-saving products designed with te advanced hydraulic model in China.
Details Images
product features
* Cast iron, duct alloy, carbon steel, zinc free bronze, silicon brass or stainless steel construction (other materials available
on request)
* High efficiency double suction impeller
* Durable, low noise, long life bearing
* Premium quality mechanical seal
* Electric or diesel drive
on request)
* High efficiency double suction impeller
* Durable, low noise, long life bearing
* Premium quality mechanical seal
* Electric or diesel drive
Application
D&DG horizontal type centrifugal pumps are used to handle clear water and other liquid has chemical and physical properties similar with the clear water limpurtity lower than 1%, particles size smaller than 0.1mm).It is applicable to city water supply and drainage for mining.The liquid temperature shall be lower than 80℃.
Product structure
Performance Paramete
|
Model
|
Capacity
|
|
Head
|
Speed
|
Motor Power
|
Impeller Dia
|
Weight
|
|
|
|
m3/h
|
L/S
|
m
|
r/min
|
(Kw)
|
mm
|
kg
|
|
|
D6-50x3
|
6.3
|
1.75
|
100
|
2950
|
11
|
198
|
140
|
|
|
D6-50x12
|
6.3
|
1.75
|
600
|
2950
|
55
|
198
|
340
|
|
|
D25-50x3
|
25
|
6.94
|
150
|
2950
|
30
|
196
|
220
|
|
|
D25-50x12
|
25
|
6.94
|
600
|
2950
|
110
|
196
|
409
|
|
|
D46-50x12
|
46
|
12.78
|
600
|
2950
|
160
|
210
|
475
|
|
|
D85-67x9
|
85
|
23.6
|
603
|
2950
|
250
|
235
|
1840
|
|
|
D120-50x2
|
120
|
33.3
|
100
|
2950
|
55
|
213
|
640
|
|
|
D120-50x9
|
120
|
33.3
|
450
|
2950
|
220
|
213
|
1200
|
|
|
D155-67x9
|
155
|
43.1
|
603
|
2950
|
450
|
235
|
1800
|
|
|
D360-40X10
|
360
|
100
|
400
|
1480
|
630
|
360
|
2550
|
|
|
D580-70X10
|
580
|
161.1
|
700
|
1480
|
1800
|
473
|
4120
|
|
|
D720-60x9
|
720
|
200
|
540
|
1480
|
1600
|
450
|
3900
|
|
