Quick Details
-
Place of Origin:
-
Guangxi, China, Guangxi china
-
Brand Name:
-
CHANGFEIXIANG
-
Dimension(L*W*H):
-
920*460*760mm
-
Weight:
-
185
-
Rated power/speed:
-
14.7/2200
-
Product name:
-
Diesel Engine
-
Engine Model:
-
YC1115M
-
Engine type:
-
Water-cooled 4-stroke
-
Application:
-
Engineering Machinery
-
MOQ:
-
5 Sets
-
Rated Power:
-
24hp
-
Type:
-
4-storkes
-
Quality:
-
High-Quality
-
After Warranty Service:
-
Provide
Quick Details
-
Displacement:
-
1.1945L
-
Emission Standard:
-
1.1945L
-
Power:
-
8HP, 30HP, 9HP, 12HP, 20HP, 15HP, 40HP, 10HP, 20 kw, 15 KW, 10 kW, 11 KW, 15.7 kw, 18.6 kW, 24hp
-
Place of Origin:
-
Guangxi, China, Guangxi china
-
Brand Name:
-
CHANGFEIXIANG
-
Dimension(L*W*H):
-
920*460*760mm
-
Weight:
-
185
-
Rated power/speed:
-
14.7/2200
-
Product name:
-
Diesel Engine
-
Engine Model:
-
YC1115M
-
Engine type:
-
Water-cooled 4-stroke
-
Application:
-
Engineering Machinery
-
MOQ:
-
5 Sets
-
Rated Power:
-
24hp
-
Type:
-
4-storkes
-
Quality:
-
High-Quality
-
After Warranty Service:
-
Provide
Product Details
Products Description
|
型号 Model
|
R180
|
R192
|
ZS195
|
ZS1100
|
ZS1105
|
ZS1110
|
|||||
|
冷却系统 Cooling system
|
水冷water cooling
|
|
|
|
|
|
|||||
|
燃油系统 Fuel system
|
柴油diesel oil
|
|
|
|
|
|
|||||
|
启动方式
Starting system
|
手启动或电启动Hand Cranking or Electric Starting
|
|
|
|
|
|
|||||
|
额定马力
Rated horsepower(HP)
|
8
|
10
|
12
|
15
|
18
|
20
|
|||||
|
额定输出
Rated output(kw)
|
5.15
|
7.35
|
8.82
|
11.03
|
12.1
|
12.5
|
|||||
|
额定转速
Rared speed(rpm)
|
2200/2600
|
|
|
|
|
|
|||||
|
内缸直径
Cylinder diameter(MM)
|
80
|
90
|
95
|
100
|
105
|
110
|
|||||
|
净重 Net weight (kg)
|
75
|
95
|
145
|
155
|
155
|
180
|
|||||
|
毛重 Gross weight (kg)
|
85
|
105
|
155
|
165
|
165
|
190
|
|||||
|
尺寸 Size (CM)
|
63*35*47
|
74*41*57
|
83*38*67
|
83*38*67
|
85*40*70
|
90*44*76
|
|||||
|
排量 Displacement (L)
|
0.402
|
0.573
|
0.852
|
0.903
|
0.996
|
1.0931
|
|||||
|
油耗 Fuel consumption (L/ KWH)
|
1.288
|
1.838
|
2.205
|
2.758
|
3.025
|
3.125
|
|||||
|
型号 Model
|
ZS1115
|
ZS1125
|
ZS1130
|
ZS1132
|
ZS1135
|
K4100D
|
|||||
|
冷却系统 Cooling system
|
水冷Water cooling
|
|
|
|
|
|
|||||
|
燃油系统 Fuel system
|
柴油Diesel oil
|
|
|
|
|
|
|||||
|
启动方式
Starting system
|
手启动或电启动Hand cranking or Electric starting
|
|
|
|
|
|
|||||
|
额定马力
Rated horsepower(HP)
|
22
|
25
|
30
|
32
|
35
|
40
|
|||||
|
额定输出
Rated output(kw)
|
16.2
|
18.4
|
22.05
|
23.52
|
25.73
|
29.41
|
|||||
|
额定转速
Rated speed(rpm)
|
2200/2600
|
|
|
|
|
|
|||||
|
内缸直径
Cylinder diameter(MM)
|
115
|
125
|
130
|
132
|
135
|
140
|
|||||
|
净重 Net weight (kg)
|
185
|
215
|
220
|
225
|
230
|
280
|
|||||
|
毛重 Gross weight (kg)
|
195
|
225
|
230
|
235
|
240
|
290
|
|||||
|
尺寸 Size (CM)
|
90*44*76
|
95*47*80
|
96*55*90
|
96*55*90
|
100*60*95
|
100*70*105
|
|||||
|
排量 Displacement (L)
|
1.1945
|
1.473
|
1.659
|
1.7
|
1.8
|
2.01
|
|||||
|
油耗 Fuel consumption (L/ KWH)
|
3.675
|
4.3
|
4.595
|
5
|
5.455
|
5.855
|
|||||
