Quick Details
-
Size:
-
according to customer demand
-
Place of Origin:
-
Shandong, China
-
Axle:
-
3Axles,13Ton/16Ton
-
Landing Gear:
-
28t Heavy Duty Landing Gear
-
Suspension:
-
Mechanical Suspension Air Suspension
-
King pin:
-
2"(50mm)or3.5"(90mm)
-
Main Beam:
-
T700/Q345 Steel
-
Rim:
-
9.00-22.5
-
Tire:
-
12R22.5
-
Leaf Spring:
-
10pcs
-
Accessory:
-
1 Set Standard Tool Box
-
Color:
-
Custom's Requirement
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
40 to 100 ton
-
Brand Name:
-
Chen Lu
-
Size:
-
according to customer demand
-
Place of Origin:
-
Shandong, China
-
Axle:
-
3Axles,13Ton/16Ton
-
Landing Gear:
-
28t Heavy Duty Landing Gear
-
Suspension:
-
Mechanical Suspension Air Suspension
-
King pin:
-
2"(50mm)or3.5"(90mm)
-
Main Beam:
-
T700/Q345 Steel
-
Rim:
-
9.00-22.5
-
Tire:
-
12R22.5
-
Leaf Spring:
-
10pcs
-
Accessory:
-
1 Set Standard Tool Box
-
Color:
-
Custom's Requirement
|
Trailer Model
|
3 Axle Low bed Semi Trailer
|
|
Dimension(Lx W x H)（mm）
|
13000*3000*3300
|
|
Curb Weight(KG)
|
8500
|
|
Loading Weight( KG)
|
50000
|
|
Total Wheight(KG)
|
75500
|
|
Axle Brand
|
13TON Axle
|
|
Axle Number
|
3
|
|
Wheelbase（mm）
|
8580+1310+1310
|
|
Suspension system
|
Mechanical suspension
|
|
Steel Spring
|
10/10/10
|
|
Frame
|
The height of the beam is500mm,upper plate is 16mm,down plate is 18mm,middle plate is 8mm.according to the buyer’s requirement
|
|
Platform plate
|
4mm Diamond Plate
|
|
Tire Type and quantity
|
8.25R20-16 12units
|
|
Traction Pin
|
50mm or 90mm
|
|
Spare Wheel Bracket
|
2 picecs
|
|
Tool Box
|
1 Unit
|
|
Landing Leg
|
28T load landing leg
|
|
Brake system
|
Dual Line braking system ,none ABS.
|
|
Brake air chamber
|
6 air chambers
|
|
Electrical system
|
24V,7 Pole plug
|
|
|
Tail lamp with turn signal, brake light & reflector, side lamp etc.
|
|
|
One set 6-core standard Cable.
|
|
Side Guard
|
None
|
|
Painting
|
Color by customer’s requirement
|
|
Packing
|
Polish with wax before shipping
|
|
Delivery way
|
Transfer to China port, and carry by ro-ro ship, the freight cost depends on the volume.
|
Q1. Are you a factory or trading company?
We are a comprehensive factory integrating product design, scientific research and development, production and sales. So we know what you're looking for. Welcome to our factory and production line at any time.
Q2. Could you accept special design and specification?
Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements. Such as: special Size, special control,or OEM, etc.
Q3. Are you looking for an agent?
Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion.
Q4. Do you have stock?
Yes we have a few stock in our warehouse for your urgent order, but the main design already finished, the only we can change are
some of the spare parts such like tires, axles, stickers, painting etc.
Q5. How to control quality?
We set up all process inspection and quality control standard, include raw materials, production process, finished products.Advanced equipment and standard inspection process ensure the quality.
Q2. Could you accept special design and specification?
Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements. Such as: special Size, special control,or OEM, etc.
Q3. Are you looking for an agent?
Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion.
Q4. Do you have stock?
Yes we have a few stock in our warehouse for your urgent order, but the main design already finished, the only we can change are
some of the spare parts such like tires, axles, stickers, painting etc.
Q5. How to control quality?
We set up all process inspection and quality control standard, include raw materials, production process, finished products.Advanced equipment and standard inspection process ensure the quality.
