Quick Details
-
Brand Name:
-
Meanwell
-
Model Number:
-
SE-1000-12
-
Output Frequency:
-
47 ~ 63Hz
-
Output Current:
-
0 ~ 83.3A
-
Rated current:
-
83.3A
-
Voltage adjustment range:
-
10 ~ 13.5V
-
efficiency:
-
85%
-
Surge current:
-
35A/115VAC 55A/230VAC
-
Leakage current:
-
<2.5mA / 240VAC
-
working temperature:
-
-20 ~ +60℃
-
Ripple and noise (maximum):
-
150mVp-p
-
Voltage accuracy:
-
±1.0%
-
Linear adjustment rate:
-
±0.5%
-
Load adjustment rate:
-
±1.0%
Quick Details
-
Input Voltage:
-
90 ~ 132VAC/180~264VAC or 254 ~ 370VDC
-
Output Voltage:
-
12V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Meanwell
-
Model Number:
-
SE-1000-12
-
Output Frequency:
-
47 ~ 63Hz
-
Output Current:
-
0 ~ 83.3A
-
Rated current:
-
83.3A
-
Voltage adjustment range:
-
10 ~ 13.5V
-
efficiency:
-
85%
-
Surge current:
-
35A/115VAC 55A/230VAC
-
Leakage current:
-
<2.5mA / 240VAC
-
working temperature:
-
-20 ~ +60℃
-
Ripple and noise (maximum):
-
150mVp-p
-
Voltage accuracy:
-
±1.0%
-
Linear adjustment rate:
-
±0.5%
-
Load adjustment rate:
-
±1.0%
Products Description
Product Paramenters
|
MODEL
|
SE-1000-5
|
SE-1000-9
|
SE-1000-12
|
SE-1000-15
|
SE-1000-24
|
SE-1000-48
|
|
DC VOLTAGE
|
5V
|
9V
|
12V
|
15V
|
24V
|
48V
|
|
RATED CURRENT
|
150A
|
100A
|
83.3A
|
66.7A
|
41.7A
|
20.8A
|
|
CURRENT RANGE
|
0~150A
|
0~100A
|
0~83.3A
|
0~66.7A
|
0~41.7A
|
0~20.8A
|
|
RATED POWER
|
750W
|
900W
|
999.6W
|
1000.5W
|
1000.8W
|
998.4W
|
|
RIPPLE & NOISE (max.)
|
150mVp-p
|
150mVp-p
|
150mVp-p
|
150mVp-p
|
200mVp-p
|
200mVp-p
|
|
VOLTAGE ADJ. RANGE
|
3.3 ~ 5.5V
|
7.5 ~ 10V
|
10 ~ 13.5V
|
13.5 ~ 16.5V
|
22 ~ 27.5V
|
43 ~ 56V
|
Product specification
