Quick Details
-
Weight:
-
100 KG
-
Product Name:
-
Disc harrows
-
Usage:
-
Agricultural Usage
-
Name:
-
Multifunctional Mini Tiller
-
Keywords:
-
Mini Land Cultivation Machine
-
Key Word:
-
Garden Power Tiller
-
Accessories:
-
Dithcing Blade
-
Working width:
-
900mm
Quick Details
-
Use:
-
Disc harrows
-
Place of Origin:
-
Austria
-
Brand Name:
-
Disc harrows
-
Weight:
-
100 KG
-
Product Name:
-
Disc harrows
-
Usage:
-
Agricultural Usage
-
Name:
-
Multifunctional Mini Tiller
-
Keywords:
-
Mini Land Cultivation Machine
-
Key Word:
-
Garden Power Tiller
-
Accessories:
-
Dithcing Blade
-
Working width:
-
900mm
folded wing heavy duty disc harrow
Agricultural machinery 1BZDZ series wing-folded heavy-duty disc harrow is suitable for crushing colds on sticky heavy clay soil land after ploughing.They can be used instead of plough on soft and loose land,Their main features are wide space operation,narrow space transportation,convenient folded wings,reliable structure with specially-used rolling bearing,easy maintenance,high productivity.
Specificatons:
|
Model |
Unit |
1BZDZ-4.4 |
1BZDZ-4.8 |
1BZDZ-5.3 |
|
Overall dimension |
cm |
580x450x150 |
580x495x150 |
580x540x150 |
|
Weight |
kg |
2800-2850 |
2950-3000 |
3100-3150 |
|
Working width |
m |
4.4 |
4.8 |
5.3 |
|
Working depth |
cm |
20 |
||
|
Blade spacing |
mm |
230 |
||
|
No of disc |
pc |
40 |
44 |
48 |
|
Dia.of disc |
mm |
660 |
|
|
|
Transport clearance |
mm |
>260 |
||
|
productivity |
ha/h |
4.4 |
4.8 |
5.3 |
|
Matched power |
kw |
105-110 |
115-120 |
125-130 |
|
Linkage |
|
Trailed |
||
