Quick Details
-
Brand Name:
-
Melongf
-
Model Number:
-
MLF- 12100 AP
-
Place of Origin:
-
Hunan, China
-
Weight:
-
/
-
The charging ratio:
-
/
-
The discharge rate:
-
/
-
Cycle life:
-
over 2000 times
-
Voltage:
-
12 Volt
-
Type:
-
Li-Ion/lithium/lifepo4
-
OEM/ODM:
-
Accepatable
-
Protection:
-
BMS Protection
-
Features:
-
Deep Cycle Life
-
Usage:
-
Power Storage
-
Apllication:
-
Household Energy Storage
-
BMS:
-
Built-in
Quick Details
-
Storage Type:
-
/
-
Anode Material:
-
LFP
-
Application:
-
Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts
-
Brand Name:
-
Melongf
-
Model Number:
-
MLF- 12100 AP
-
Place of Origin:
-
Hunan, China
-
Weight:
-
/
-
The charging ratio:
-
/
-
The discharge rate:
-
/
-
Cycle life:
-
over 2000 times
-
Voltage:
-
12 Volt
-
Type:
-
Li-Ion/lithium/lifepo4
-
OEM/ODM:
-
Accepatable
-
Protection:
-
BMS Protection
-
Features:
-
Deep Cycle Life
-
Usage:
-
Power Storage
-
Apllication:
-
Household Energy Storage
-
BMS:
-
Built-in
Battery Parameters
|
Serial number |
Project |
Parameter |
|
1 |
Battery Type |
Lithium iron phosphate battery |
|
3 |
Rated capacity (Ah) |
≥ 100 |
|
4 |
Rated voltage (V) |
3.2 |
|
5 |
Internal resistance (mΩ) |
≤ 0.4 |
|
6 |
Continuous discharge current (C) |
1 |
|
7 |
Maximum instantaneous discharge current 10S |
2 |
|
8 |
Standard charging current |
0.5 |
|
9 |
Fast charge flow |
1 |
|
10 |
Charging temperature range |
0~45 |
|
11 |
Discharge temperature range |
- 20 - 55 |
|
12 |
Storage humidity range (RH) |
≤85% |
Battery System Parameters
|
Serial number |
Project name |
Standard requirement |
Condition |
|
|
1 |
Operating Voltage |
1 0~ 14.6 V |
|
|
|
2 |
Battery capacity |
100 Ah |
1 parallel 100 Ah lithium iron phosphate aluminum shell battery combination
|
|
|
3 |
Battery energy
|
1280 Wh |
25°C (100% DOD @ 1C rate) |
|
|
|
960 Wh |
-20°C (100% DOD @ 1C rate) |
||
|
4 |
Weight |
≤ 11 kg |
|
|
|
5 |
Chassis size
|
Width |
172 mm |
|
|
|
Long |
330 mm |
|
|
|
|
High |
215 mm |
|
|
|
6 |
Chassis material |
2mm thick environmentally friendly plastic |
|
|
|
7 |
Continuous charging current |
50 A |
|
|
|
8 |
Peak discharge current |
200 A (duration 2S) |
Subject to BMS setting parameters |
|
|
9 |
Rated discharge current |
100 A |
|
|
|
10 |
Charging cut-off voltage |
14.6 V |
Calculated according to 3.65V voltage of each cell |
|
|
11 |
Discharge cut-off voltage |
10 V |
Calculated according to 2.5V voltage of each cell |
|
|
12 |
Charging method |
CC-CV |
Constant current and constant voltage charging |
|
|
13 |
Self-discharge |
≤2% per month |
25°C |
|
|
14 |
Temperature characteristics |
-20°C— 55°C |
Ambient temperature for normal operation |
|
|
15 |
Storage temperature |
0~45 |
|
|
Battery Protection
Battery Advantages
Hot Sale Product
LiFePO4 is a lithium-iron-phosphate battery that offers significant advantages over batteries in other technologies.
Thanks to the long service life of over 2000 cycles, they provide us with over 10 years of use, and high current efficiency and over 3 times less weight than the equivalent in acid technology -leaded, ideally suited as a power source in motorhomes, s, electric vehicles or solar installations.
Applications
1.Energy Storage:Solar-Wind Power System / City Grid (On/Off) / Community and Family / RV Motorhome /Golf Carts Battery / Boat
Marine Yachts / Electric Skateboard / Vehecle.
2.Back-up System and UPS:Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / Military Equipment.
3.Other Applications:Security and Electronics / Mobile POS, Mining Light / Tourch / LED Light / Emergency Light / LED Backup /Engine Starting Battery,etc.
