Quick Details
-
Marketing Type:
-
New Product 2022
-
Weight (KG):
-
1110 KG
-
Power (kW):
-
11.65
-
Name:
-
automatic wood polishing machines
-
Maximum processing width:
-
1000mm
-
Polishing thickness:
-
10-160mm
-
Length of processed plate:
-
≥350mm
-
Polishing roller speed:
-
Variable speed FM
-
Belt speed:
-
5-20m/min
-
Diameter of polishing roller:
-
300mm
-
Total motor capacity:
-
11.65kw
-
Key words:
-
Wood Processing Equipment
-
Usage:
-
Making Wood Sawdust Briquettes
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Joway
-
Machine Type:
-
polishing machine
-
Marketing Type:
-
New Product 2022
-
Weight (KG):
-
1110 KG
-
Power (kW):
-
11.65
-
Name:
-
automatic wood polishing machines
-
Maximum processing width:
-
1000mm
-
Polishing thickness:
-
10-160mm
-
Length of processed plate:
-
≥350mm
-
Polishing roller speed:
-
Variable speed FM
-
Belt speed:
-
5-20m/min
-
Diameter of polishing roller:
-
300mm
-
Total motor capacity:
-
11.65kw
-
Key words:
-
Wood Processing Equipment
-
Usage:
-
Making Wood Sawdust Briquettes
Product Description
automatic wood polishing machines
Suitable for PVC, veneer, melamine, plastic, etc materials. (U-shaped can be customized).There are 9 discs in total, all of which
are inverted U-shaped, which can be quickly replaced. There are 9 longitudinal rolls.Sisal or DuPont silk can be selected for two
straight rolls. The mesh number of abrasive belt is 80-600, which can be selected according to needs. This machine is suitable for
all kinds of plate solid wood furniture. Primer and white stubble can be polished. The polishing thickness is 10-160 mm.
Conduct machine debugging and operation to ensure normal use of the machine.
Details Images
Grind and polish the groove surface of the solid wood board.
2 discs+2 straight rollers, customizable according to requirements.
Specification
|
automatic wood polishing machines
|
|
|
|
Model
|
1000-4S
|
|
|
Maximum processing width
|
1000mm
|
|
|
Polishing thickness
|
10-150mm
|
|
|
Processing plate length
|
≥350mm
|
|
|
Polishing roller diameter
|
300mm
|
|
|
Polishing roller speed
|
variable speed frequency modulation
|
|
|
Conveyor belt speed
|
5-20m/min
|
|
|
Total motor capacity
|
7.75kw
|
|
|
Straight roller motor
|
2.2kw×2
|
|
|
Conveying motor
|
0.75kw
|
|
|
Lifting motor
|
0.55kw-RV40
|
|
|
Disc motor
|
1.5w six-stage
|
|
|
Disc swing motor
|
0.55kw-RV40
|
|
|
Delivery size
|
2400×1750×1890mm
|
|
|
Net machine weight
|
1.11 tons
|
|
|
Use size
|
2950×1750×2160mm
|
|
|
Individual wooden box weight
|
150kg
|
|
|
Wooden box size
|
2480×1820×2150mm
|
|
Optional Parts
Joway high-quality brand polishing machine.1000-1300MM width, multiple operating programs available for selection. Processing solid wood boards, primer boards.
Accessories
Sandpaper accessories can be customized according to the required number of sandpaper mesh.
Products Packaging
Use sturdy wooden boxes for packaging and transportation.
