Quick Details
-
Cell size:
-
1250*380mm
-
Panel Dimensions:
-
1320*420mm
-
Panel Efficiency:
-
21%-22.8%, 22.8%
-
Product name:
-
BIPV Roof Solar Tiles & System
-
Weight:
-
3.5 KG
-
SIZE:
-
1320*420mm
-
Color:
-
Black (custom any color)
-
Power output:
-
75W/Piece
-
Operating Temperature:
-
-45°C ~ 85°C / -49°F ~ 185°F
-
Certificate:
-
CE, IEC 61215, IEC 61730, 3C, ISO 9001:2015, ISO 14001:2015,
-
Warranty:
-
30 Years
Quick Details
-
Brand Name:
-
QUACENT
-
Model Number:
-
Solar Roof Tile
-
Place of Origin:
-
Liaoning, China
-
Cell size:
-
1250*380mm
-
Panel Dimensions:
-
1320*420mm
-
Panel Efficiency:
-
21%-22.8%, 22.8%
-
Product name:
-
BIPV Roof Solar Tiles & System
-
Weight:
-
3.5 KG
-
SIZE:
-
1320*420mm
-
Color:
-
Black (custom any color)
-
Power output:
-
75W/Piece
-
Operating Temperature:
-
-45°C ~ 85°C / -49°F ~ 185°F
-
Certificate:
-
CE, IEC 61215, IEC 61730, 3C, ISO 9001:2015, ISO 14001:2015,
-
Warranty:
-
30 Years
|
PV Shingle Dimensions
|
|
13200*420MM
|
|
|
Effective PV Dimensions
|
|
1250*380MM
|
|
|
Units / m
2
|
|
2 Units / m2
|
|
|
Weight
|
|
3.5 KG
|
|
|
Base
|
|
Stone Coated Metal Roofing
|
|
|
PV Module Materials
|
Cell Type
|
Right-angle black monocrystalline
|
|
|
|
Cell Amount
|
12 pieces
|
|
|
|
Facing Material
|
3.2mm super white coated tempered glass
|
|
|
|
Backing Material
|
Black double-sided fluorinated coating
|
|
|
|
Cable Connectors
|
MC4 or MC4 Adapted
|
|
|
Electrical Characteristics
|
Max. output power
|
75W/Unit
|
|
|
|
Open-circuit voltage
|
8.06V
|
|
|
|
Max. open-circuit voltage
|
6V
|
|
|
|
Short-circuit current
|
12.72A
|
|
|
|
Max. operating current
|
9.48A
|
|
|
Operating Characteristics
|
Operating temperature
|
-45℃ ~ 85℃
|
|
|
|
Max. system voltage
|
500V
|
|
|
|
Operating temperature
|
45℃
|
|
